suntan, freckling and sunburn are familiar effects of over-exposure, along with higher risk of skin cancer. Living things on dry land would be severely damaged by ultraviolet radiation from the Sun if most of it were not filtered out by the Earth's atmosphere. More-energetic, shorter-wavelength "extreme" UV below 121 nm ionizes air so strongly that it is absorbed before it reaches the ground. Ultraviolet is also responsible for the formation of bone-strengthening vitamin D in most land vertebrates, including humans. The UV spectrum thus has effects both beneficial and harmful to human health.
Ultraviolet rays are invisible to most humans: the lens in a human eye ordinarily filters out UVB frequencies or higher, and humans lack color receptor adaptations for ultraviolet rays. Under some conditions, children and young adults can see ultraviolet down to wavelengths of about 310 nm, and people with aphakia (missing lens) or replacement lens can also see some UV wavelengths. Near-UV radiation is visible to some insects, mammals, and birds. Small birds have a fourth color receptor for ultraviolet rays; this gives birds "true" UV vision. Reindeer use near-UV radiation to see polar bears, who are poorly visible in regular light because they blend in with the snow. UV also allows mammals to see urine trails, which is helpful for prey animals to find food in the wild. The males and females of some butterfly species look identical to the human eye but very different to UV-sensitive eyes—the males sport bright patterns in order to attract the females.
Ultraviolet trailer hd
"Ultraviolet" means "beyond violet" (from Latin ultra, "beyond"), violet being the color of the highest frequencies of visible light. Ultraviolet has a higher frequency than violet light.
UV radiation was discovered in 1801 when the German physicist Johann Wilhelm Ritter observed that invisible rays just beyond the violet end of the visible spectrum darkened silver chloride-soaked paper more quickly than violet light itself. He called them "oxidizing rays" to emphasize chemical reactivity and to distinguish them from "heat rays", discovered the previous year at the other end of the visible spectrum. The simpler term "chemical rays" was adopted shortly thereafter, and it remained popular throughout the 19th century, although there were those who held that these were an entirely different sort of radiation from light (notably John William Draper, who named them "tithonic rays"). The terms chemical and heat rays were eventually dropped in favour of ultraviolet and infrared radiation, respectively. In 1878 the effect of short-wavelength light on sterilizing bacteria was discovered. By 1903 it was known the most effective wavelengths were around 250 nm. In 1960, the effect of ultraviolet radiation on DNA was established.
The discovery of the ultraviolet radiation below 200 nm, named vacuum ultraviolet because it is strongly absorbed by air, was made in 1893 by the German physicist Victor Schumann.
The electromagnetic spectrum of ultraviolet radiation (UVR), defined most broadly as 10–400 nanometers, can be subdivided into a number of ranges recommended by the ISO standard ISO-21348:
A variety of solid-state and vacuum devices have been explored for use in different parts of the UV spectrum. Many approaches seek to adapt visible light-sensing devices, but these can suffer from unwanted response to visible light and various instabilities. Ultraviolet can be detected by suitable photodiodes and photocathodes, which can be tailored to be sensitive to different parts of the UV spectrum. Sensitive ultraviolet photomultipliers are available. Spectrometers and radiometers are made for measurement of UV radiation. Silicon detectors are used across the spectrum.
People cannot perceive UV directly, since the lens of the human eye blocks most radiation in the wavelength range of 300–400 nm; shorter wavelengths are blocked by the cornea. Nevertheless, the photoreceptors of the retina are sensitive to near-UV, and people lacking a lens (a condition known as aphakia) perceive near-UV as whitish-blue or whitish-violet.
Vacuum UV, or VUV, wavelengths (shorter than 200 nm) are strongly absorbed by molecular oxygen in the air, though the longer wavelengths of about 150–200 nm can propagate through nitrogen. Scientific instruments can therefore utilize this spectral range by operating in an oxygen-free atmosphere (commonly pure nitrogen), without the need for costly vacuum chambers. Significant examples include 193 nm photolithography equipment (for semiconductor manufacturing) and circular dichroism spectrometers.
Technology for VUV instrumentation was largely driven by solar astronomy for many decades. While optics can be used to remove unwanted visible light that contaminates the VUV, in general, detectors can be limited by their response to non-VUV radiation, and the development of "solar-blind" devices has been an important area of research. Wide-gap solid-state devices or vacuum devices with high-cutoff photocathodes can be attractive compared to silicon diodes.
Extreme UV (EUV or sometimes XUV) is characterized by a transition in the physics of interaction with matter. Wavelengths longer than about 30 nm interact mainly with the outer valence electrons of atoms, while wavelengths shorter than that interact mainly with inner-shell electrons and nuclei. The long end of the EUV spectrum is set by a prominent He+ spectral line at 30.4 nm. EUV is strongly absorbed by most known materials, but it is possible to synthesize multilayer optics that reflect up to about 50% of EUV radiation at normal incidence. This technology was pioneered by the NIXT and MSSTA sounding rockets in the 1990s, and has been used to make telescopes for solar imaging.
Very hot objects emit UV radiation (see black-body radiation). The Sun emits ultraviolet radiation at all wavelengths, including the extreme ultraviolet where it crosses into X-rays at 10 nm. Extremely hot stars emit proportionally more UV radiation than the Sun. Sunlight in space at the top of Earth's atmosphere (see solar constant) is composed of about 50% infrared light, 40% visible light, and 10% ultraviolet light, for a total intensity of about 1400 W/m2 in vacuum.
However, at ground level sunlight is 44% visible light, 3% ultraviolet (with the Sun at its zenith), and the remainder infrared. Thus, the atmosphere blocks about 77% of the Sun's UV, almost entirely in the shorter UV wavelengths, when the Sun is highest in the sky (zenith). Of the ultraviolet radiation that reaches the Earth's surface, more than 95% is the longer wavelengths of UVA, with the small remainder UVB. There is essentially no UVC. The fraction of UVB which remains in UV radiation after passing through the atmosphere is heavily dependent on cloud cover and atmospheric conditions. Thick clouds block UVB effectively; but in "partly cloudy" days, patches of blue sky showing between clouds are also sources of (scattered) UVA and UVB, which are produced by Rayleigh scattering in the same way as the visible blue light from those parts of the sky.
The shorter bands of UVC, as well as even more-energetic UV radiation produced by the Sun, are absorbed by oxygen and generate the ozone in the ozone layer when single oxygen atoms produced by UV photolysis of dioxygen react with more dioxygen. The ozone layer is especially important in blocking most UVB and the remaining part of UVC not already blocked by ordinary oxygen in air.
Blockers and absorbers
Ultraviolet absorbers are molecules used in organic materials (polymers, paints, etc.) to absorb UV radiation to reduce the UV degradation (photo-oxidation) of a material. The absorbers can themselves degrade over time, so monitoring of absorber levels in weathered materials is necessary.
In sunscreen, ingredients that absorb UVA/UVB rays, such as avobenzone, oxybenzone and octyl methoxycinnamate, are organic chemical absorbers or "blockers". They are contrasted with inorganic absorbers/"blockers" of UV radiation such as titanium dioxide and zinc oxide.
For clothing, the Ultraviolet Protection Factor (UPF) represents the ratio of sunburn-causing UV without and with the protection of the fabric, similar to SPF (Sun Protection Factor) ratings for sunscreen. Standard summer fabrics have UPF of approximately 6, which means that about 20% of UV will pass through.
Suspended nanoparticles in stained glass prevent UV rays from causing chemical reactions that change image colors. A set of stained glass color reference chips is planned to be used to calibrate the color cameras for the 2019 ESA Mars rover mission, since they will remain unfaded by the high level of UV present at the surface of Mars.
Common soda lime glass is partially transparent to UVA but is opaque to shorter wavelengths, whereas fused quartz glass, depending on quality, can be transparent even to vacuum UV wavelengths. Ordinary window glass passes about 90% of the light above 350 nm, but blocks over 90% of the light below 300 nm.
Wood's glass is a nickel-bearing form of glass with a deep blue-purple color that blocks most visible light and passes ultraviolet.
Human health-related effects
The impact of ultraviolet radiation on human health has implications for the risks and benefits of sun exposure, and is also implicated in issues such as fluorescent lamps and health. Getting too much sun exposure can be harmful, but in moderation is beneficial.
The benefits of UV can outweigh manageable risks. UV light causes the body to produce vitamin D, which is essential for life. The human body needs some UV radiation in order for one to maintain adequate vitamin D levels.
Reasonable exposure to ultraviolet radiation from the sun can be a good source of vitamin D. One minimal erythemal dose of sunlight UV radiation provides the equivalent of about 20,000 IU of vitamin D2, taken as an oral supplement. If an adult’s arms and legs are exposed to a half minimal erythemal UV radiation, it is the same as taking 3,000 IU of vitamin D3 through an oral supplement. This exposure of 10–15 minutes, on a frequency of two to three times per week will cause the adult's skin to produce enough vitamin D. It is not necessary to expose the face to the UV, as facial skin provides little vitamin D3. Individuals whose metabolism makes taking oral vitamin D ineffective are able, through exposure to an ultraviolet lamp that emits UV-B radiation, to achieve a 25 (OH) D blood level.
Three benefits of UV exposure are production of vitamin D, improvement in mood, and increased energy.
UVB induces production of vitamin D in the skin at rates of up to 1,000 IUs per minute. This vitamin helps to regulate calcium metabolism (vital for the nervous system and bone health), immunity, cell proliferation, insulin secretion, and blood pressure. In third-world countries, foods fortified with vitamin D are "practically nonexistent." Most people in the world depend on the sun to get vitamin D.
Only a handful of foods have vitamin D. Examples are cod liver oil and oily fish. A person would have to eat oily fish three or four times per week in order to get enough vitamin D from that food source alone. If people cannot get sunlight, then they will need 1,000 IU of vitamin D per day to stay healthy. There are not many foods that naturally have vitamin D.
People with higher levels of vitamin D tend to have lower rates of diabetes, heart disease, and stroke and tend to have lower blood pressure. However, it has been found that vitamin D supplementation does not improve cardiovascular health or metabolism, so the link with vitamin D must be in part indirect. People who get more sun are generally healthier, and also have higher vitamin D levels. It has been found that ultraviolet radiation (even UVA) produces nitric oxide (NO) in the skin, and nitric oxide can lower blood pressure. High blood pressure increases the risk of stroke and heart disease. Although long-term exposure to ultraviolet contributes to non-melanoma skin cancers that are rarely fatal, it has been found in a Danish study that those who get these cancers were less likely to die during the study, and were much less likely to have a heart attack, than those who did not have these cancers.
People in certain situations, such as people with intellectual disabilities and neurodevelopmental disorders who stay inside most of the time have low vitamin D levels. Getting enough vitamin D can help stave off "autoimmune diseases, cardiovascular disease, many types of cancer, dementia, types 1 and 2 diabetes mellitus, and respiratory tract infections."
Fetuses and children who do not get enough vitamin D can suffer from "growth retardation and skeletal deformities."
Cardiovascular and hypertension
Worldwide, one billion people suffer from hypertension. In the U.S., half of the 146 million hypertensive patients don't have their blood pressure under control. In hypertension patients who suffer from vitamin D deficiency, UVB radiation (but not UVA) lowered blood pressure.
Modern pharmaceutical therapy has resulted in an overall reduction in hypertension, particularly in countries with high GDP per capita. A review of blood pressure statistics before these pharmaceuticals were available shows a coherent correlation between high blood pressure and higher latitude. Seasons of the year also impact high blood pressure; BP is lower in the summer months in high latitudes than it is in the winter, when there is less sunlight. Individuals with more sun exposure synthesize more active vitamin D (1,25 di-hydroxy cholecalciferol) from diet or ultraviolet radiation exposure. A combination of lower ultraviolet radiation with insufficient vitamin D in a diet leads to vitamin D deficiency. Individuals whose vitamin D ranks in the lowest quartile have double the all cause mortality of those who rank in the highest quartile. They are also more likely to suffer from cardiovascular disease, hypertension and organ cancer.
Medical trials have demonstrated that vitamin D supplements do not prevent or treat hypertension or cardiovascular disease, although they can help in skeletal metabolism. Epidemiological and observational studies show indications that exposure to ultraviolet radiation, particularly sunlight, might reduce all-cause mortality and can help reduce cardiovascular disease and hypertension. One hundred years of scientific data has demonstrated that the effect of ultraviolet radiation on human skin is carcinogenic. There is a lack of evidence that this carcinogenic effect, like risks such as smoking or alcohol, is responsible for higher mortality. There are significant archives of studies demonstrating that ultraviolet radiation from sunlight provides measurable health benefits, independent of vitamin D.
Vitamin D promotes the creation of serotonin. The production of serotonin is in direct proportion to the degree of bright sunlight the body receives. Conversely, serotonin levels decrease when sunlight is at its lowest levels, as in autumn and winter.
Changes in serotonin levels affect how humans act relative to mood and behavior. Measured serotonin is much higher among those who die in summer, rather than winter.
Serotonin is a monoamine neurotransmitter that is thought to provide sensations of happiness, well being and serenity to human beings.
It is thought that serotonin affects a plethora of human bodily functions from anxiety and mood to bowel function to bone density to sexuality. Its importance in human activity continues to be a source of much scientific examination and experimentation.
The amount of the brown pigment melanin in the skin increases after exposure to UV radiation at moderate levels depending on skin type; this is commonly known as a sun tan. melanin is an excellent photoprotectant that absorbs both UVB and UVA radiation and dissipates the energy as harmless heat, protecting the skin against both direct and indirect DNA damage.
"There is no doubt that a little sunlight is good for you!” - World Health Organization
In humans, excessive exposure to UV radiation can result in acute and chronic harmful effects on the skin, eye, and immune system.
The differential effects of various wavelengths of light on the human cornea and skin are sometimes called the "erythemal action spectrum.". The action spectrum shows that UVA does not cause immediate reaction, but rather UV begins to cause photokeratitis and skin redness (with Caucasians more sensitive) at wavelengths starting near the beginning of the UVB band at 315 nm, and rapidly increasing to 300 nm. The skin and eyes are most sensitive to damage by UV at 265–275 nm, which is in the lower UVC band. At still shorter wavelengths of UV, damage continues to happen, but the overt effects are not as great with so little penetrating the atmosphere. The WHO-standard ultraviolet index is a widely publicized measurement of total strength of UV wavelengths that cause sunburn on human skin, by weighting UV exposure for action spectrum effects at a given time and location. This standard shows that most sunburn happens due to UV at wavelengths near the boundary of the UVA and UVB bands. Bioolympics discover UV reaction index to detect the leak of UV light.
Overexposure to UVB radiation not only can cause sunburn but also some forms of skin cancer. However, the degree of redness and eye irritation (which are largely not caused by UVA) do not predict the long-term effects of UV, although they do mirror the direct damage of DNA by ultraviolet.
All bands of UV radiation damage collagen fibers and accelerate aging of the skin. Both UVA and UVB destroy vitamin A in skin, which may cause further damage.
UVB radiation can cause direct DNA damage. This cancer connection is one reason for concern about ozone depletion and the ozone hole.
The most deadly form of skin cancer, malignant melanoma, is mostly caused by DNA damage independent from UVA radiation. This can be seen from the absence of a direct UV signature mutation in 92% of all melanoma. Occasional overexposure and sunburn are probably greater risk factors for melanoma than long-term exposure. UVC is the highest-energy, most-dangerous type of ultraviolet radiation, and causes adverse effects that can variously be mutagenic or carcinogenic.
In the past, UVA was considered not harmful or less harmful than UVB, but today it is known to contribute to skin cancer via indirect DNA damage (free radicals such as reactive oxygen species). UVA can generate highly reactive chemical intermediates, such as hydroxyl and oxygen radicals, which in turn can damage DNA. The DNA damage caused indirectly to skin by UVA consists mostly of single-strand breaks in DNA, while the damage caused by UVB includes direct formation of thymine dimers or other pyrimidine dimers, and double-strand DNA breakage. UVA is immunosuppressive for the entire body (accounting for a large part of the immunosuppressive effects of sunlight exposure), and is mutagenic for basal cell keratinocytes in skin.
UVB photons can cause direct DNA damage. UVB radiation excites DNA molecules in skin cells, causing aberrant covalent bonds to form between adjacent pyrimidine bases, producing a dimer. Most UV-induced pyrimidine dimers in DNA are removed by the process known as nucleotide excision repair that employs about 30 different proteins. Those pyrimidine dimers that escape this repair process can induce a form of programmed cell death (apoptosis) or can cause DNA replication errors leading to mutation.
As a defense against UV radiation, the amount of the brown pigment melanin in the skin increases when exposed to moderate (depending on skin type) levels of radiation; this is commonly known as a sun tan. The purpose of melanin is to absorb UV radiation and dissipate the energy as harmless heat, blocking the UV from damaging skin tissue. UVA gives a quick tan that lasts for days by oxidizing melanin that was already present and triggers the release of the melanin from melanocytes. UVB yields a tan that takes roughly 2 days to develop because it stimulates the body to produce more melanin.
Sunscreen prevents the direct DNA damage which causes sunburn. Most of these products contain an SPF rating to show how well they block UVB rays. The SPF rating, however, offers no data about UVA protection.
Sunscreen safety debate
Medical organizations recommend that patients protect themselves from UV radiation by using sunscreen. Five sunscreen ingredients have been shown to protect mice against skin tumors. However, some sunscreen chemicals produce potentially harmful substances if they are illuminated while in contact with living cells. The amount of sunscreen that penetrates into the lower layers of the skin may be large enough to cause damage.
Sunscreen reduces the direct DNA damage that causes sunburn, by blocking UVB, and the usual SPF rating indicates how effectively this radiation is blocked. SPF is, therefore, also called UVB-PF, for "UVB protection factor". This rating, however, offers no data about important protection against UVA, which does not primarily cause sunburn but is still harmful, since it causes indirect DNA damage and is also considered carcinogenic. Several studies suggest that the absence of UVA filters may be the cause of the higher incidence of melanoma found in sunscreen users compared to non-users.
The photochemical properties of melanin make it an excellent photoprotectant. However, sunscreen chemicals cannot dissipate the energy of the excited state as efficiently as melanin and therefore, if sunscreen ingredients penetrate into the lower layers of the skin, the amount of reactive oxygen species may be increased. The amount of sunscreen that penetrates through the stratum corneum may or may not be large enough to cause damage.
In an experiment by Hanson et al. that was published in 2006, the amount of harmful reactive oxygen species (ROS) was measured in untreated and in sunscreen treated skin. In the first 20 minutes, the film of sunscreen had a protective effect and the number of ROS species was smaller. After 60 minutes, however, the amount of absorbed sunscreen was so high that the amount of ROS was higher in the sunscreen treated skin than in the untreated skin. The study indicates that sunscreen must be reapplied within 2 hours in order to prevent UV light from penetrating to sunscreen-infused live skin cells.
Aggravation of certain skin conditions
Ultraviolet radiation can aggravate several skin conditions and diseases, including:
The eye is most sensitive to damage by UV in the lower UVC band at 265–275 nm. Radiation of this wavelength is almost absent from sunlight, but is found in welder's arc lights and other artificial sources. Exposure to these can cause "welder's flash" or "arc eye" (photokeratitis), and can lead to cataracts, pterygium and pinguecula formation. To a lesser extent, UVB in sunlight from 310–280 nm also causes photokeratitis ("snow blindness"), and the cornea, the lens, and the retina can be damaged.
Protective eyewear is beneficial to those exposed to ultraviolet radiation. Since light can reach the eyes from the sides, full-coverage eye protection is usually warranted if there is an increased risk of exposure, as in high-altitude mountaineering. Mountaineers are exposed to higher-than-ordinary levels of UV radiation, both because there is less atmospheric filtering and because of reflection from snow and ice. Ordinary, untreated eyeglasses give some protection. Most plastic lenses give more protection than glass lenses, because, as noted above, glass is transparent to UVA and the common acrylic plastic used for lenses is less so. Some plastic lens materials, such as polycarbonate, inherently block most UV.
Degradation of polymers, pigments and dyes
UV degradation is one form of polymer degradation that affects plastics exposed to sunlight. The problem appears as discoloration or fading, cracking, loss of strength or disintegration. The effects of attack increases with exposure time and sunlight intensity. The addition of UV absorbers inhibits the effect.
Sensitive polymers include thermoplastics and speciality fibers like aramids. UV absorption leads to chain degradation and loss of strength at sensitive points in the chain structure. Aramid rope must be shielded with a sheath of thermoplastic if it is to retain its strength.
Many pigments and dyes absorb UV and change colour, so paintings and textiles may need extra protection both from sunlight and fluorescent bulbs, two common sources of UV radiation. Window glass absorbs some harmful UV, but valuable artifacts need extra shielding. Many museums place black curtains over watercolour paintings and ancient textiles, for example. Since watercolours can have very low pigment levels, they need extra protection from UV. Various forms of picture framing glass, including acrylics (plexiglass), laminates, and coatings, offer different degrees of UV (and visible light) protection.
Because of its ability to cause chemical reactions and excite fluorescence in materials, ultraviolet radiation has a number of applications. The following table gives some uses of specific wavelength bands in the UV spectrum
Photographic film responds to ultraviolet radiation but the glass lenses of cameras usually block radiation shorter than 350 nm. Slightly yellow UV-blocking filters are often used for outdoor photography to prevent unwanted bluing and overexposure by UV rays. For photography in the near UV, special filters may be used. Photography with wavelengths shorter than 350 nm requires special quartz lenses which do not absorb the radiation. Digital cameras sensors may have internal filters that block UV to improve color rendition accuracy. Sometimes these internal filters can be removed, or they may be absent, and an external visible-light filter prepares the camera for near-UV photography. A few cameras are designed for use in the UV.
Photography by reflected ultraviolet radiation is useful for medical, scientific, and forensic investigations, in applications as wide spread as detecting bruising of skin, alterations of documents, or restoration work on paintings. Photography of the fluorescence produced by ultraviolet illumination uses visible wavelengths of light.
In ultraviolet astronomy, measurements are used to discern the chemical composition of the interstellar medium, and the temperature and composition of stars. Because the ozone layer blocks many UV frequencies from reaching telescopes on the surface of the Earth, most UV observations are made from space.
Electrical and electronics industry
EPROMs (Erasable Programmable Read-Only Memory) are erased by exposure to UV radiation. These modules have a transparent (quartz) window on the top of the chip that allows the UV radiation in.
Fluorescent dye uses
Colorless fluorescent dyes that emit blue light under UV are added as optical brighteners to paper and fabrics. The blue light emitted by these agents counteracts yellow tints that may be present, and causes the colors and whites to appear whiter or more brightly colored.
UV fluorescent dyes that glow in the primary colors are used in paints, papers and textiles either to enhance color under daylight illumination, or to provide special effects when lit with UV lamps. Blacklight paints that contain dyes that glow under UV are used in a number of art and esthetic applications.
To help prevent counterfeiting of currency, or forgery of important documents such as driver's licenses and passports, the paper may include a UV watermark or fluorescent multicolor fibers that are visible under ultraviolet light. Postage stamps are tagged with a phosphor that glows under UV rays to permit automatic detection of the stamp and facing of the letter.
UV fluorescent dyes are used in many applications (for example, biochemistry and forensics). Some brands of pepper spray will leave an invisible chemical (UV dye) that is not easily washed off on a pepper-sprayed attacker, which would help police identify the attacker later.
In some types of nondestructive testing UV stimulates fluorescent dyes to highlight defects in a broad range of materials. These dyes may be carried into surface-breaking defects by capillary action (liquid penetrant inspection) or they may be bound to ferrite particles caught in magnetic leakage fields in ferrous materials (magnetic particle inspection).
UV is an investigative tool at the crime scene helpful in locating and identifying bodily fluids such as semen, blood, and saliva. For example, ejaculated fluids or saliva can be detected by high-power UV sources, irrespective of the structure or colour of the surface the fluid is deposited upon. UV-Vis microspectroscopy is also used to analyze trace evidence, such as textile fibers and paint chips, as well as questioned documents.
Other applications include the authentication of various collectibles and art, and detecting counterfeit currency. Even materials not specially marked with UV sensitive dyes may have distinctive fluorescence under UV exposure, or may fluoresce differently under short-wave versus long-wave ultraviolet.
Enhancing contrast of ink
Using multi-spectral imaging it is possible to read illegible papyrus, such as the burned papyri of the Villa of the Papyri or of Oxyrhynchus, or the Archimedes palimpsest. The technique involves taking pictures of the illegible document using different filters in the infrared or ultraviolet range, finely tuned to capture certain wavelengths of light. Thus, the optimum spectral portion can be found for distinguishing ink from paper on the papyrus surface.
Simple NUV sources can be used to highlight faded iron-based ink on vellum.
Ultraviolet aids in the detection of organic material deposits that remain on surfaces where periodic cleaning and sanitizing may not have been properly accomplished. The phenyl and indole chemical moieties in proteins absorb UV, and are made visible by blocking the fluorescence of the material beneath them—often UV brighteners in fabrics. Detergents are easily detected using UV inspection. In "ABS" or alkylbenzenesulfonate detergents, the substituted benzine absorbs UV. Phosphate detergents with a phenyl moiety also absorb.
Pet urine deposits in carpeting or other hard surfaces can be detected for accurate treatment and removal of mineral traces and the odor-causing bacteria that feed on proteins in urine. Many hospitality industries use UV lamps to inspect for unsanitary bedding to determine life-cycle for mattress restoration, as well as general performance of the cleaning staff. A perennial news feature for many television news organizations involves an investigative reporter's using a similar device to reveal unsanitary conditions in hotels, public toilets, hand rails, and such.
UV/VIS spectroscopy is widely used as a technique in chemistry to analyze chemical structure, the most notable one being conjugated systems. UV radiation is often used to excite a given sample where the fluorescent emission is measured with a spectrofluorometer. In biological research, UV radiation is used for quantification of nucleic acids or proteins.
In pollution control applications, ultraviolet analyzers are used to detect emissions of nitrogen oxides, sulfur compounds, mercury and ammonia, for example in the flue gas of fossil fired power plants. Ultraviolet radiation can detect thin sheens of spilled oil on water, either by the high reflectivity of oil films at UV wavelengths, fluorescence of compounds in oil, or by absorbing of UV created by Raman scattering in water.
In general, ultraviolet detectors use either a solid-state device, such as one based on silicon carbide or aluminium nitride, or a gas-filled tube as the sensing element. UV detectors that are sensitive to UV in any part of the spectrum respond to irradiation by sunlight and artificial light. A burning hydrogen flame, for instance, radiates strongly in the 185- to 260-nanometer range and only very weakly in the IR region, whereas a coal fire emits very weakly in the UV band yet very strongly at IR wavelengths; thus, a fire detector that operates using both UV and IR detectors is more reliable than one with a UV detector alone. Virtually all fires emit some radiation in the UVC band, whereas the Sun's radiation at this band is absorbed by the Earth's atmosphere. The result is that the UV detector is "solar blind", meaning it will not cause an alarm in response to radiation from the Sun, so it can easily be used both indoors and outdoors.
UV detectors are sensitive to most fires, including hydrocarbons, metals, sulfur, hydrogen, hydrazine, and ammonia. Arc welding, electrical arcs, lightning, X-rays used in nondestructive metal testing equipment (though this is highly unlikely), and radioactive materials can produce levels that will activate a UV detection system. The presence of UV-absorbing gases and vapors will attenuate the UV radiation from a fire, adversely affecting the ability of the detector to detect flames. Likewise, the presence of an oil mist in the air or an oil film on the detector window will have the same effect.
Ultraviolet radiation is used for very fine resolution photolithography, a procedure wherein a chemical called a photoresist is exposed to UV radiation that has passed through a mask. The exposure causes chemical reactions to occur in the photoresist. After removal of unwanted photoresist, a pattern determined by the mask remains on the sample. Steps may then be taken to "etch" away, deposit on or otherwise modify areas of the sample where no photoresist remains.
Photolithography is used in the manufacture of semiconductors, integrated circuit components, and printed circuit boards. Photolithography processes used to fabricate electronic integrated circuits presently use 193 nm UV, and are experimentally using 13.5 nm UV for Extreme ultraviolet lithography.
Electronic components that require clear transparency for light to exit or enter (photo voltaic panels and sensors) can be potted using acrylic resins that are cured using UV energy. The advantages are low VOC emissions and rapid curing.
Certain inks, coatings, and adhesives are formulated with photoinitiators and resins. When exposed to UV light, polymerization occurs, and so the adhesives harden or cure, usually within a few seconds. Applications include glass and plastic bonding, optical fiber coatings, the coating of flooring, UV coating and paper finishes in offset printing, dental fillings, and decorative finger nail "gels".
UV sources for UV curing applications include UV lamps, UV LEDs, and Excimer flash lamps. Fast processes such as flexo or offset printing require high-intensity light focused via reflectors onto a moving substrate and medium so high-pressure Hg (mercury) or Fe (iron, doped)-based bulbs are used, energized with electric arcs or microwaves. Lower-power fluorescent lamps and LEDs can be used for static applications. Small high-pressure lamps can have light focused and transmitted to the work area via liquid-filled or fiber-optic light guides.
The impact of UV on polymers is used for modification of the (roughness and hydrophobicity) of polymer surfaces. For example, a poly(methyl methacrylate) surface can be smoothed by vacuum ultraviolet.
UV radiation is useful in preparing low-surface-energy polymers for adhesives. Polymers exposed to UV will oxidize, thus raising the surface energy of the polymer. Once the surface energy of the polymer has been raised, the bond between the adhesive and the polymer is stronger.
Using a catalytic chemical reaction from titanium dioxide and UVC exposure, oxidation of organic matter converts pathogens, pollens, and mold spores into harmless inert byproducts. The cleansing mechanism of UV is a photochemical process. Contaminants in the indoor environment are almost entirely organic carbon-based compounds, which break down when exposed to high-intensity UV at 240 to 280 nm. Short-wave ultraviolet radiation can destroy DNA in living microorganisms. UVC's effectiveness is directly related to intensity and exposure time.
UV has also been shown to reduce gaseous contaminants such as carbon monoxide and VOCs. UV lamps radiating at 184 and 254 nm can remove low concentrations of hydrocarbons and carbon monoxide, if the air is recycled between the room and the lamp chamber. This arrangement prevents the introduction of ozone into the treated air. Likewise, air may be treated by passing by a single UV source operating at 184 nm and passed over iron pentaoxide to remove the ozone produced by the UV lamp.
Sterilization and disinfection
Ultraviolet lamps are used to sterilize workspaces and tools used in biology laboratories and medical facilities. Commercially available low-pressure mercury-vapor lamps emit about 86% of their radiation at 254 nanometers (nm), which is near one of the peaks of the germicidal effectiveness curve. UV at these germicidal wavelengths damage a microorganism's DNA so that it cannot reproduce, making it harmless, (even though the organism may not be killed). Since microorganisms can be shielded from ultraviolet rays in small cracks and other shaded areas, these lamps are used only as a supplement to other sterilization techniques.
Disinfection using UV radiation is commonly used in wastewater treatment applications and is finding an increased usage in municipal drinking water treatment. Many bottlers of spring water use UV disinfection equipment to sterilize their water. Solar water disinfection has been researched for cheaply treating contaminated water using natural sunlight. The UV-A irradiation and increased water temperature kill organisms in the water.
Ultraviolet radiation is used in several food processes to kill unwanted microorganisms. UV can be used to pasteurize fruit juices by flowing the juice over a high-intensity ultraviolet source. The effectiveness of such a process depends on the UV absorbance of the juice.
Pulsed light (PL) is a technique of killing microorganisms on surfaces using pulses of an intense broad spectrum, rich in UV-C between 200 and 280 nm. Pulsed light works with Xenon flash lamps that can produce flashes several times per second. Disinfection robots use pulsed UV
Some animals, including birds, Reptiles, and insects such as bees, can see near-ultraviolet wavelengths. Many fruits, flowers, and seeds stand out more strongly from the background in ultraviolet wavelengths as compared to human color vision. Scorpions glow or take on a yellow to green color under UV illumination, thus assisting in the control of these arachnids. Many birds have patterns in their plumage that are invisible at usual wavelengths but observable in ultraviolet, and the urine and other secretions of some animals, including dogs, cats, and human beings, is much easier to spot with ultraviolet. Urine trails of rodents can be detected by pest control technicians for proper treatment of infested dwellings.
Butterflies use ultraviolet as a communication system for sex recognition and mating behavior. For example, in the Colias eurytheme butterfly, males rely on visual cues to locate and identify females. Instead of using chemical stimuli to find mates, males are attracted to the ultraviolet-absorbing color of female hind wings.
Many insects use the ultraviolet wavelength emissions from celestial objects as references for flight navigation. A local ultraviolet emitter will normally disrupt the navigation process and will eventually attract the flying insect.
The green fluorescent protein (GFP) is often used in genetics as a marker. Many substances, such as proteins, have significant light absorption bands in the ultraviolet that are of interest in biochemistry and related fields. UV-capable spectrophotometers are common in such laboratories.
Ultraviolet traps called bug zappers are used to eliminate various small flying insects. They are attracted to the UV, and are killed using an electric shock, or trapped once they come into contact with the device. Different designs of ultraviolet radiation traps are also used by entomologists for collecting nocturnal insects during faunistic survey studies.
Ultraviolet radiation is helpful in the treatment of skin conditions such as psoriasis and vitiligo. Exposure to UVA while the skin is hyper-photosensitive by taking psoralens is an effective treatment for psoriasis. Due to the potential of psoralens to cause damage to the liver, PUVA therapy may be used only a limited number of times over a patient's lifetime.
UVB phototherapy does not require additional medications or topical preparations for the therapeutic benefit; only the exposure is needed. However, phototherapy can be effective when used in conjunction with certain topical treatments such as anthralin, coal tar, and Vitamin A and D derivatives, or systemic treatments such as methotrexate and soriatane.
Reptiles need UVB for synthesis of vitamin D, which in turn is needed to metabolize calcium for bone and egg production. UVA wavelengths are also visible to many reptiles and play an important role in visual feedback. Thus, in a typical reptile enclosure, a fluorescent UV lamp should be available for vitamin D synthesis. This should be combined with the provision of heat for basking, either by the same lamp or another.
In January 2017 it was reported that the rare Spiky Yellow Woodlouse, endemic to Saint Helena, fluoresces under Ultraviolet light. Notoriously hard to spot, this discovery made determining population numbers of this endangered species much easier.
The evolution of early reproductive proteins and enzymes is attributed in modern models of evolutionary theory to ultraviolet radiation. UVB causes thymine base pairs next to each other in genetic sequences to bond together into thymine dimers, a disruption in the strand that reproductive enzymes cannot copy. This leads to frameshifting during genetic replication and protein synthesis, usually killing the cell. Before formation of the UV-blocking ozone layer, when early prokaryotes approached the surface of the ocean, they almost invariably died out. The few that survived had developed enzymes that monitored the genetic material and removed thymine dimers by nucleotide excision repair enzymes. Many enzymes and proteins involved in modern mitosis and meiosis are similar to repair enzymes, and are believed to be evolved modifications of the enzymes originally used to overcome DNA damages caused by UV.
