Smart polymers or stimuli-responsive polymers are high-performance polymers that change according to the environment they are in. Such materials can be sensitive to a number of factors, such as temperature, humidity, pH, the wavelength or intensity of light or an electrical or magnetic field and can respond in various ways, like altering colour or transparency, becoming conductive or permeable to water or changing shape (shape memory polymers). Usually, slight changes in the environment are sufficient to induce large changes in the polymer’s properties.

Contents

Smart polymer Silver formation

Smart polymers appear in highly specialised applications and everyday products alike. They are used for the production of hydrogels, biodegradable packaging, and to a great extent in biomedical engineering. One example is a polymer that undergoes conformational change in response to pH change, which can be used in drug delivery.

Smart polymer Smart polymers

The nonlinear response of smart polymers is what makes them so unique and effective. A significant change in structure and properties can be induced by a very small stimulus. Once that change occurs, there is no further change, meaning a predictable all-or-nothing response occurs, with complete uniformity throughout the polymer. Smart polymers may change conformation, adhesiveness or water retention properties, due to slight changes in pH, ionic strength, temperature or other triggers.

Smart polymer Smart polymers

Another factor in the effectiveness of smart polymers lies in the inherent nature of polymers in general. The strength of each molecule’s response to changes in stimuli is the composite of changes of individual monomer units which, alone, would be weak. However, these weak responses, compounded hundreds or thousands of times, create a considerable force for driving biological processes.

Smart polymer A smart polymer kit for composing tailored novel materials

Stimuli

Smart polymer Temperature and lightresponsive smart polymer materials Chemical

Several polymer systems respond to temperature, undergoing an lower critical solution temperature phase transition. One of the better-studied such polymers is poly(N-isopropylacryamide), with a transition temperature of approximately 33 °C. Several homologous N-alkyl acrylamides also show LCST behavior, with the transition temperature depending on the length of the hydrophobic side chain. Above their transition temperature, these polymers become insoluble in water. This behavior is believed to be entropy driven.

Classification and chemistry

Smart polymer University Studying Smart Polymer Film to Control Substrates

Currently, the most prevalent use for smart polymers in biomedicine is for specifically targeted drug delivery. Since the advent of timed-release pharmaceuticals, scientists have been faced with the problem of finding ways to deliver drugs to a particular site in the body without having them first degrade in the highly acidic stomach environment. Prevention of adverse effects to healthy bone and tissue is also an important consideration. Researchers have devised ways to use smart polymers to control the release of drugs until the delivery system has reached the desired target. This release is controlled by either a chemical or physiological trigger.

Linear and matrix smart polymers exist with a variety of properties depending on reactive functional groups and side chains. These groups might be responsive to pH, temperature, ionic strength, electric or magnetic fields, and light. Some polymers are reversibly cross-linked by noncovalent bonds that can break and reform depending on external conditions. Nanotechnology has been fundamental in the development of certain nanoparticle polymers such as dendrimers and fullerenes, that have been applied for drug delivery. Traditional drug encapsulation has been done using lactic acid polymers. More recent developments have seen the formation of lattice-like matrices that hold the drug of interest integrated or entrapped between the polymer strands.

Smart polymer matrices release drugs by a chemical or physiological structure-altering reaction, often a hydrolysis reaction resulting in cleavage of bonds and release of drug as the matrix breaks down into biodegradable components. The use of natural polymers has given way to artificially synthesized polymers such as polyanhydrides, polyesters, polyacrylic acids, poly(methyl methacrylates), and polyurethanes. Hydrophilic, amorphous, low-molecular-weight polymers containing heteroatoms (i.e., atoms other than carbon) have been found to degrade fastest. Scientists control the rate of drug delivery by varying these properties thus adjusting the rate of degradation.

A graft-and-block copolymer is two different polymers grafted together. A number of patents already exist for different combinations of polymers with different reactive groups. The product exhibits properties of both individual components which adds a new dimension to a smart polymer structure, and may be useful for certain applications. Cross-linking hydrophobic and hydrophilic polymers results in formation of micelle-like structures that can protectively assist drug delivery through aqueous medium until conditions at the target location cause simultaneous breakdown of both polymers.

A graft-and-block approach might be useful for solving problems encountered by the use of a common bioadhesive polymer, polyacrylic acid (PAAc). PAAc adheres to mucosal surfaces but will swell and degrade rapidly at pH 7.4, resulting in rapid release of drugs entrapped in its matrix. A combination of PAAc with another polymer that is less sensitive to changes at neutral pH might increase the residence time and slow the release of the drug, thus improving bioavailability and effectiveness.

Hydrogels are polymer networks that do not dissolve in water but swell or collapse in changing aqueous environments. They are useful in biotechnology for phase separation because they are reusable or recyclable. New ways to control the flow, or catch and release of target compounds, in hydrogels, are being investigated. Highly specialized hydrogels have been developed for the delivery and release of drugs into specific tissues. Hydrogels made from PAAc are especially common because of their bioadhesive properties and tremendous absorbency.

enzyme immobilization in hydrogels is a fairly well-established process. Reversibly cross-linked polymer networks and hydrogels can be similarly applied to a biological system where the response and release of a drug is triggered by the target molecule itself. Alternatively, the response might be turned on or off by the product of an enzyme reaction. This is often done by incorporating an enzyme, receptor or antibody, that binds to the molecule of interest, into the hydrogel. Once bound, a chemical reaction takes place that triggers a reaction from the hydrogel. The trigger can be oxygen, sensed using oxidoreductase enzymes, or a pH-sensing response. An example of the latter is combined entrapment of glucose oxidase and insulin in a pH-responsive hydrogel. In the presence of glucose, the formation of gluconic acid by the enzyme triggers release of insulin from the hydrogel.

Two criteria for this technology to work effectively are enzyme stability and rapid kinetics (quick response to the trigger and recovery after removal of the trigger). Several strategies have been tested in type 1 diabetes research, involving the use of similar types of smart polymers that can detect changes in blood glucose levels and trigger production or release of insulin. Likewise, there are many possible applications of similar hydrogels as drug delivery agents for other conditions and diseases.

Other Applications

Smart polymers are not just for drug delivery. Their properties make them especially suited for bioseparations. The time and costs involved in purifying proteins might be reduced significantly by using smart polymers that undergo rapid reversible changes in response to a change in medium properties. Conjugated systems have been used for many years in physical and affinity separations and immunoassays. Microscopic changes in the polymer structure are manifested as precipitate formation, which may be used to aid separation of trapped proteins from solution.

These systems work when a protein or other molecule that is to be separated from a mix, forms a bioconjugate with the polymer, and precipitates with the polymer when its environment undergoes a change. The precipitate is removed from the media, thus separating the desired component of the conjugate from the rest of the mixture. Removal of this component from the conjugate depends on recovery of the polymer and a return to its original state, thus hydrogels are very useful for such processes.

Another approach to controlling biological reactions using smart polymers is to prepare recombinant proteins with built-in polymer binding sites close to ligand or cell binding sites. This technique has been used to control ligand and cell binding activity, based on a variety of triggers including temperature and light.

Future applications

It has been suggested that polymers might be developed that can learn and self-correct behavior over time. Although this might be a far distant possibility, there are other more feasible applications that appear to be coming in the near future. One of these is the idea of smart toilettes that analyze urine and help identify health problems. In environmental biotechnology, smart irrigation systems have been also been proposed. It would be incredibly useful to have a system that turns on and off, and controls fertilizer concentrations, based on soil moisture, pH and nutrient levels. Many creative approaches to targeted drug delivery systems that self-regulate based on their unique cellular surroundings, are also under investigation.

There are obvious possible problems associated with the use of smart polymers in biomedicine. The most worrisome is the possibility of toxicity or incompatibility of artificial substances in the body, including degradation products and byproducts. However, smart polymers have enormous potential in biotechnology and biomedical applications if these obstacles can be overcome.
