Vitruvius

Life and career

Little is known about Vitruvius' life. Most inferences about him are extracted from his only surviving work De Architectura. Even his first name Marcus and his cognomen Pollio are uncertain. Cetius Faventinus writes of "Vitruvius Polio aliique auctores"; this can be read as "Vitruvius Polio, and others" or, less likely, as "Vitruvius, Polio, and others". An inscription in Verona, which names a Lucius Vitruvius Cordo, and an inscription from Thilbilis in North Africa, which names a Marcus Vitruvius Mamurra have been suggested as evidence that Vitruvius and Mamurra (who was a military praefectus fabrum under Julius Caesar) were from the same family; or were even the same individual. Neither association, however, is borne out by De Architectura (which Vitruvius dedicated to Augustus), nor by the little that is known of Mamurra.

Vitruvius was a military engineer (praefectus fabrum), or a praefect architectus armamentarius of the apparitor status group (a branch of the Roman civil service). He is mentioned in Pliny the Elder's table of contents for Naturalis Historia (Natural History), in the heading for mosaic techniques. Frontinus refers to "Vitruvius the architect" in his late 1st-century work De aquaeductu.

Likely born a free Roman citizen, by his own account, Vitruvius served the Roman army under Caesar with the otherwise poorly identified Marcus Aurelius, Publius Minidius, and Gnaeus Cornelius. These names vary depending on the edition of De architectura. Publius Minidius is also written as Publius Numidicus and Publius Numidius, speculated as the same Publius Numisius inscribed on the Roman Theatre at Heraclea.

As an army engineer he specialized in the construction of ballista and scorpio artillery war machines for sieges. It is speculated that Vitruvius served with Caesar's chief engineer Lucius Cornelius Balbus.

The locations where he served can be reconstructed from, for example, descriptions of the building methods of various "foreign tribes". Although he describes places throughout De Architectura, he does not say he was present. His service likely included north Africa, Hispania, Gaul (including Aquitaine) and Pontus.

To place the role of Vitruvius the military engineer in context, a description of "The Prefect of the camp" or army engineer is quoted here as given by Flavius Vegetius Renatus in The Military Institutions of the Romans:

The Prefect of the camp, though inferior in rank to the [Prefect], had a post of no small importance. The position of the camp, the direction of the entrenchments, the inspection of the tents or huts of the soldiers and the baggage were comprehended in his province. His authority extended over the sick, and the physicians who had the care of them; and he regulated the expenses relative thereto. He had the charge of providing carriages, bathhouses and the proper tools for sawing and cutting wood, digging trenches, raising parapets, sinking wells and bringing water into the camp. He likewise had the care of furnishing the troops with wood and straw, as well as the rams, onagri, balistae and all the other engines of war under his direction. This post was always conferred on an officer of great skill, experience and long service, and who consequently was capable of instructing others in those branches of the profession in which he had distinguished himself.

At various locations described by Vitruvius, battles and sieges occurred. He is the only source for the siege of Larignum in 56 BC. Of the battlegrounds of the Gallic War there are references to: the siege and massacre of the 40,000 residents at Avaricum in 52 BC; Vercingetorix commented that "the Romans did not conquer by valor nor in the field, but by a kind of art and skill in assault, with which they [Gauls] themselves were unacquainted." The broken siege at Gergovia in 52 BC. The circumvallation and Battle of Alesia in 52 BC; the women and children of the encircled city were evicted to conserve food, where they starved to death between the opposing walls of the defenders and besiegers. And the siege of Uxellodunum in 51 BC. These are all sieges of large Gallic oppida. Of the sites involved in Caesar's civil war, we find the Siege of Massilia in 49 BC, the Battle of Dyrrhachium of 48 BC (modern Albania), the Battle of Pharsalus in 48 BC (Hellas – Greece), the Battle of Zela of 47 BC (modern Turkey) and the Battle of Thapsus in 46 BC in Caesar's African campaign. A legion that fits the same sequence of locations is the Legio VI Ferrata, of which ballista would be an auxiliary unit.

Mainly known for his writings, Vitruvius was himself an architect. In Roman times architecture was a broader subject than at present including the modern fields of architecture, construction management, construction engineering, chemical engineering, civil engineering, materials engineering, mechanical engineering, military engineering and urban planning; architectural engineers consider him the first of their discipline, a specialization previously known as technical architecture. Frontinus mentions him in connection with the standard sizes of pipes. He is often credited as father of architectural acoustics for describing the technique of echeas placement in theaters. The only building, however, that we know Vitruvius to have worked on is one he tells us about, a basilica completed in 19 BC. It was built at Fanum Fortunae, now the modern town of Fano. The Basilica di Fano (to give the building its Italian name) has disappeared so completely that its very site is a matter of conjecture, although various attempts have been made to visualise it. The early Christian practice of converting Roman basilicae (public buildings) into cathedrals implies the basilica may be incorporated into the cathedral located in Fano.

In later years the emperor Augustus, through his sister Octavia Minor, sponsored Vitruvius, entitling him with what may have been a pension to guarantee financial independence. Whether De architectura was written by one author or is a compilation completed by subsequent librarians and copyists, remains an open question. The date of his death is unknown, which suggests that he had enjoyed only little popularity during his lifetime.

Gerolamo Cardano, in his 1552 book De subtilitate rerum, ranks Vitruvius as one of the 12 persons whom he supposes to have excelled all men in the force of genius and invention; and would not have scrupled to have given him the first place, if it could be imagined that he had delivered nothing but his own discoveries.

De Architectura

Vitruvius is the author of De architectura, known today as The Ten Books on Architecture, a treatise written in Latin on architecture, dedicated to the emperor Augustus. In the preface of Book I, Vitruvius dedicates his writings so as to give personal knowledge of the quality of buildings to the emperor. Likely Vitruvius is referring to Marcus Agrippa's campaign of public repairs and improvements. This work is the only surviving major book on architecture from classical antiquity. According to Petri Liukkonen, this text "influenced deeply from the Early Renaissance onwards artists, thinkers, and architects, among them Leon Battista Alberti (1404–1472), Leonardo da Vinci (1452–1519), and Michelangelo (1475–1564)." The next major book on architecture, Alberti's reformulation of Ten Books, was not written until 1452.

Vitruvius is famous for asserting in his book De architectura that a structure must exhibit the three qualities of firmitas, utilitas, venustas – that is, it must be solid, useful, beautiful. These are sometimes termed the Vitruvian virtues or the Vitruvian Triad. According to Vitruvius, architecture is an imitation of nature. As birds and bees built their nests, so humans constructed housing from natural materials, that gave them shelter against the elements. When perfecting this art of building, the Greeks invented the architectural orders: Doric, Ionic and Corinthian. It gave them a sense of proportion, culminating in understanding the proportions of the greatest work of art: the human body. This led Vitruvius in defining his Vitruvian Man, as drawn later by Leonardo da Vinci: the human body inscribed in the circle and the square (the fundamental geometric patterns of the cosmic order).

Scope

Vitruvius is sometimes loosely referred to as the first architect, but it is more accurate to describe him as the first Roman architect to have written surviving records of his field. He himself cites older but less complete works. He was less an original thinker or creative intellect than a codifier of existing architectural practice. It should also be noted that Vitruvius had a much wider scope than modern architects. Roman architects practised a wide variety of disciplines; in modern terms, they could be described as being engineers, architects, landscape architects, surveyors, artists, and craftsmen combined. Etymologically the word architect derives from Greek words meaning 'master' and 'builder'. The first of the Ten Books deals with many subjects which now come within the scope of landscape architecture.

In Book I, Chapter 1, titled The Education of the Architect, Vitruvius instructs...

1. Architecture is a science arising out of many other sciences, and adorned with much and varied learning; by the help of which a judgment is formed of those works which are the result of other arts. Practice and theory are its parents. Practice is the frequent and continued contemplation of the mode of executing any given work, or of the mere operation of the hands, for the conversion of the material in the best and readiest way. Theory is the result of that reasoning which demonstrates and explains that the material wrought has been so converted as to answer the end proposed.

2. Wherefore the mere practical architect is not able to assign sufficient reasons for the forms he adopts; and the theoretic architect also fails, grasping the shadow instead of the substance. He who is theoretic as well as practical, is therefore doubly armed; able not only to prove the propriety of his design, but equally so to carry it into execution.

He goes on to say that the architect should be versed in drawing, geometry, optics (lighting), history, philosophy, music, theatre, medicine, and law.

In Book I, Chapter 3 (The Departments of Architecture), Vitruvius divides architecture into three branches, namely; building; the construction of sundials and water clocks; and the design and use of machines in construction and warfare. He further divides building into public and private. Public building includes city planning, public security structures such as walls, gates and towers; the convenient placing of public facilities such as theatres, forums and markets, baths, roads and pavings; and the construction and position of shrines and temples for religious use. Later books are devoted to the understanding, design and construction of each of these.

Proportions of Man

In Book III, Chapter 1, Paragraph 3, Vitruvius writes about the proportions of man...

3. Just so the parts of Temples should correspond with each other, and with the whole. The navel is naturally placed in the centre of the human body, and, if in a man lying with his face upward, and his hands and feet extended, from his navel as the centre, a circle be described, it will touch his fingers and toes. It is not alone by a circle, that the human body is thus circumscribed, as may be seen by placing it within a square. For measuring from the feet to the crown of the head, and then across the arms fully extended, we find the latter measure equal to the former; so that lines at right angles to each other, enclosing the figure, will form a square.

It was upon these writings that Leonardo da Vinci based his Vitruvian Man.

Vitruvius described the human figure as being the principal source of proportion.

The drawing itself is often used as an implied symbol of the essential symmetry of the human body, and by extension, of the universe as a whole.

Lists of names given in Book VII Introduction

In the introduction to book seven, Vitruvius goes to great lengths to present why he is qualified to write De Architectura. This is the only location in the work where Vitruvius specifically addresses his personal breadth of knowledge. Similar to a modern reference section, the author's position as one who is knowledgeable and educated is established. The topics range across many fields of expertise reflecting that in Roman times as today construction is a diverse field. Vitruvius is clearly a well-read man.

In addition to providing his qualification, Vitruvius summarizes a recurring theme throughout the 10 books, a non-trivial and core contribution of his treatise outside simply a construction book. Vitruvius makes the point that the work of some of the most talented are unknown, while many who are of lesser talent but greater political position are famous. This theme runs through Vitruvius’s ten books repeatedly – echoing an implicit prediction that his works and himself will also be unknown. Which was true for over a thousand years after he completed the 10 books.

Vitruvius illustrates this point by naming what he considers are the most talented individuals in history. Implicitly challenging the reader that they have never heard of some of these people, Vitruvius goes on and predicts that some of these individuals will be forgotten and their works will be lost, while other less deserving political characters of history will be forever remembered with pageantry.

Rediscovery

Vitruvius' De architectura was rediscovered in 1414 by the Florentine humanist Poggio Bracciolini. Leon Battista Alberti (1404–1472) publicised it in his seminal treatise on architecture, De re aedificatoria (c. 1450). The first known Latin printed edition was by Fra Giovanni Sulpitius in Rome, 1486. Translations followed in Italian (Como, 1521), French (Jean Martin, 1547, English, German (Walter H. Ryff, 1543) and Spanish and several other languages. The original illustrations had been lost and the first illustrated edition was published in Venice in 1511 with woodcut illustrations, based on descriptions in the text, probably by Fra Giovanni Giocondo. Later in the 16th-century Andrea Palladio provided illustrations for Daniele Barbaro's commentary on Vitruvius, published in Italian and Latin versions. The most famous illustration is probably Da Vinci's Vitruvian Man.

The surviving ruins of Roman antiquity, the Roman Forum, temples, theatres, triumphal arches and their reliefs and statues offered visual examples of the descriptions in the Vitruvian text. Printed and illustrated editions of De Architectura inspired Renaissance, Baroque and Neoclassical architecture. Filippo Brunelleschi, for example, invented a new type of hoist to lift the large stones for the dome of the cathedral in Florence and was inspired by De Architectura as well as surviving Roman monuments such as the Pantheon and the Baths of Diocletian.

Notable editions

Latin

Italian

French

English

Roman technology

Books VIII, IX and X form the basis of much of what we know about Roman technology, now augmented by archaeological studies of extant remains, such as the water mills at Barbegal in France. The other major source of information is the Naturalis Historia compiled by Pliny the Elder much later in c. 75 AD.

Machines

The work is important for its descriptions of the many different machines used for engineering structures such as hoists, cranes and pulleys, as well as war machines such as catapults, ballistae, and siege engines. As a practising engineer, Vitruvius must be speaking from personal experience rather than simply describing the works of others. He also describes the construction of sundials and water clocks, and the use of an aeolipile (the first steam engine) as an experiment to demonstrate the nature of atmospheric air movements (wind).

Aqueducts

His description of aqueduct construction includes the way they are surveyed, and the careful choice of materials needed, although Frontinus (a general who was appointed in the late 1st century AD to administer the many aqueducts of Rome), writing a century later, gives much more detail of the practical problems involved in their construction and maintenance. Surely Vitruvius' book would have been of great assistance in this. Vitruvius was writing in the 1st century BC when many of the finest Roman aqueducts were built, and survive to this day, such as those at Segovia and the Pont du Gard. The use of the inverted siphon is described in detail, together with the problems of high pressures developed in the pipe at the base of the siphon, a practical problem with which he seems to be acquainted.

Materials

He describes many different construction materials used for a wide variety of different structures, as well as such details as stucco painting. Concrete and lime receive in-depth descriptions.

Vitruvius is cited as one of the earliest sources to connect lead mining and manufacture, its use in drinking water pipes, and its adverse effects on health. For this reason, he recommended the use of clay pipes and masonry channels in the provision of piped drinking-water.

Vitruvius is the source for the anecdote that credits Archimedes with the discovery of the mass-to-volume ratio while relaxing in his bath. Having been asked to investigate the suspected adulteration of the gold used to make a crown, Archimedes realised that the crown's volume could be measured exactly by its displacement of water, and ran into the street with the cry of Eureka!

Dewatering machines

He describes the construction of Archimedes' screw in Chapter X (without mentioning Archimedes by name). It was a device widely used for raising water to irrigate fields and drain mines. Other lifting machines he mentions include the endless chain of buckets and the reverse overshot water-wheel. Remains of the water wheels used for lifting water were discovered when old mines were re-opened at Rio Tinto in Spain, Rosia Montana in Romania and Dolaucothi in west Wales. The Rio Tinto wheel is now shown in the British Museum, and the Dolaucothi specimen in the National Museum of Wales.

Surveying instruments

That he must have been well practised in surveying is shown by his descriptions of surveying instruments, especially the water level or chorobates, which he compares favourably with the groma, a device using plumb lines. They were essential in all building operations, but especially in aqueduct construction, where a uniform gradient was important to the provision of a regular supply of water without damage to the walls of the channel. He also developed one of the first odometers, consisting of a wheel of known circumference that dropped a pebble into a container on every rotation.

Central heating

He describes the many innovations made in building design to improve the living conditions of the inhabitants. Foremost among them is the development of the hypocaust, a type of central heating where hot air developed by a fire was channelled under the floor and inside the walls of public baths and villas. He gives explicit instructions how to design such buildings so that fuel efficiency is maximised, so that for example, the caldarium is next to the tepidarium followed by the frigidarium. He also advises on using a type of regulator to control the heat in the hot rooms, a bronze disc set into the roof under a circular aperture which could be raised or lowered by a pulley to adjust the ventilation. Although he does not suggest it himself, it is likely that his dewatering devices such as the reverse overshot water-wheel was used in the larger baths to lift water to header tanks at the top of the larger thermae, such as the Baths of Diocletian. The one which was used in Bath of Caracalla for grinding flour.
