Official name Barragem da Valeira Purpose Power Construction began 1971 | Country Portugal Status Operational Annual generation 610.7 GWh | |
 | ||
Location municipality São João da Pesqueira, Viseu District Address CM1121, São João da Pesqueira, Portugal Hours Open today · Open 24 hoursTuesdayOpen 24 hoursWednesdayOpen 24 hoursThursdayOpen 24 hoursFridayOpen 24 hoursSaturdayOpen 24 hoursSundayOpen 24 hoursMondayOpen 24 hoursSuggest an edit Dam volume 220,000 m3 (7,800,000 cu ft) Spillway capacity 18,000 m3/s (640,000 cu ft/s) Similar Douro, Carrapatelo Dam, Pocinho Dam, Crestuma‑Lever Dam, Régua Dam | ||
Valeira dam portugal
Valeira Dam (Portuguese: Barragem da Valeira) is a concrete gravity dam on the Douro, where the river forms the border line between the districts of Viseu and Bragança. It is located in the municipality São João da Pesqueira, in Viseu District, Portugal.
Contents
- Valeira dam portugal
- Valeira dam flying over stock footage videohive 15587139
- DamEdit
- ReservoirEdit
- Power plantEdit
- LockEdit
- References
Construction of the dam began in 1971. The dam was completed in 1975. It is owned by Companhia Portuguesa de Produção de Electricidade (CPPE).
Valeira dam flying over stock footage videohive 15587139
DamEdit
Valeira Dam is a 48 m tall (height above foundation) and 380 m long gravity dam with a crest altitude of 113 m. The volume of the dam is 220,000 m³. The spillway with 5 radial gates is part of the dam body (maximum discharge 18,000 m³/s).
ReservoirEdit
At full reservoir level of 105 m the reservoir of the dam has a surface area of 7.95 km² and a total capacity of 97 mio. m³. The active capacity is 8 (12, 13 or 13,04) mio. m³.
Power plantEdit
The run-of-the-river hydroelectric power plant was commissioned in 1976 (1975). It is operated by EDP. The plant has a nameplate capacity of 240 (216) MW. Its average annual generation is 610.7 (663, 748 or 801) GWh.
The power station contains 3 Kaplan turbine-generators with 82.4 (72) MW (80 MVA) each in a dam powerhouse located on the right side of the dam. The turbine rotation is 115.4 rpm. The minimum hydraulic head is 15.5 m, the maximum 31.5 m. Maximum flow per turbine is 360 m³/s.
The turbines were provided by Kværner, the generators by Brown, Boveri & Cie.
LockEdit
On the left side of the dam is a lock, which can handle ships with the following maximum properties: 83 m in length, 11.40 m on the beam, 3.8 m load-draught and a cargo capacity of 2500 tons.
