The troland (symbol Td), named after Leonard T. Troland, is a unit of conventional retinal illuminance. It is meant as a method for correcting photometric measurements of luminance values impinging on the human eye by scaling them by the effective pupil size. It is equal to retinal illuminance produced by a surface whose luminance is one nit when the apparent area of the entrance pupil of the eye is 1 square millimeter.
Contents
- Intro 28 para troland sa
- Troland minha av
- Units conversion
- Physical quantities
- Unit system
- Basic unit dimensions
- Comparisons
- References
The troland typically refers to the ordinary or photopic troland, which is defined in terms of the photopic luminance:
where L is the photopic luminance in cd m−2 and p is pupil area in mm2.
A scotopic troland is also sometimes defined:
where L′ is the scotopic luminance in cd m−2 and p is pupil area in mm2.
Although named "retinal luminance", Trolands should not be confused with actual photons flux incident on a retina Lr. Conversion between the two is dependent of the specific eye optical parameters and not done by a simple units conversion factor.
Troland minha av
Units conversion
Troland does not directly convert to other units, being a retinal luminance per unit area of a pupil.
However Troland is linked to retinal luminance in lux = lm/m^2 as follows. Assuming the corneal luminance L from an extended source, the pupil diameter p and the focal length of the eye F, the retinal luminance is:
Lr [lm / m^2] = pi * L / 4 / (f/#)^2 ~ pi * L * p^2 / 4 / F^2.
Multiplying by the pupil area : Trolands [cd / m^2 * mm^2] = L * pi * p^2 / 4 = F^2 * Lr ~ 289 * Lr.
Alternatively, the retinal luminance Lr [lm/m^2] = Trolands / 289 [mm^2]
As provided by a more accurate optical calculations, the conversion factor is 278 rather than 289 as demonstrated by simplified considerations above.
Sometimes (by convention only, although not rigorously accurate by definition), retinal luminance is expressed in [cd/m^2] = [lm/sr /m^2]. Assuming a Lambertian surface, 1 cd/m^2 = pi lm/m^2 = pi lux. That is, 1 [cd/m^2] = 289/pi [Troland] ~ 92 [Troland]
Physical quantities
Unit system
centimeter-gram-second (cgs)
Basic unit dimensions
[length]^(-2) [luminous intensity]
