Opening date 2018 (Scheduled) Height 19 m Construction began December 1995 | Impounds Ohio River Length 791 m Impound Ohio River | |
 | ||
Location Pulaski County, Illinois / Ballard County, Kentucky United States Construction cost Estimated $2.918 billion Operator(s) United States Army Corps of Engineers Louisville District | ||
Olmsted locks and dam moving stilling basin shell 2 with super gantry crane
The Olmsted Locks and Dam is a locks and concrete dam project currently under construction on the Ohio River at river mile 964.4 to replace Locks and Dam 52 and 53 to greatly reduce tow and barge delays. The locks are located about 17 miles upstream from the confluence of the Ohio and Mississippi rivers at Olmsted, Illinois.
Contents
- Olmsted locks and dam moving stilling basin shell 2 with super gantry crane
- Map of Olmsted Lock 26 Dam New Dam Rd La Center KY 42056 USA
- Olmsted locks and dam will be hub for inland waterways commerce
- HistoryEdit
- References
Map of Olmsted Lock %26 Dam, New Dam Rd, La Center, KY 42056, USA
The project is both the largest and the most expensive inland waterway project ever undertaken in the United States.
Olmsted locks and dam will be hub for inland waterways commerce
HistoryEdit
The US Congress first approved a $775 million budget for the project in 1988. The lock chambers, completed in 2002, are 110 feet (34 m) wide and 1,200 feet (370 m) long.
According to the US Army Corps of Engineers, the new dam and locks will reduce passage time to under one hour with the new system. Due to queuing at Lock and Dam Number 52 and Lock and Dam Number 53, it can take cargo traffic 15 to 20 hours each to transit the locks the Olmsted complex is intended to replace.
When initiated the complex was projected to cost $775 million. As of November 2016, the estimated cost of the project is approaching $3 billion.
While the project was initially scheduled for completion in 1998, by 2016 it was projected to become operational between 2018 and 2020. The New York Times reports that, according to the United States Army Corps of Engineers, the Federal agency responsible for maintaining navigation on the USA's rivers, the delay in completing the lock complex costs $640 million per year, due to delays at the aging locks at Lock and Dam Number 52 and Lock and Dam Number 53, which it will replace.
