Area less than one acre NRHP Reference # 89001207 Opened 1983 Body of water Ashuelot River Architect William Leonard Kingsbury | Built 1863 (1863) Address Gilsum, NH 03448, USA Longest span 15 m Added to NRHP 31 August 1989 | |
 | ||
Location Surry Rd. over the Ashuelot River W of jct. NH 10, Gilsum, New Hampshire Architectural style Dry Masonry Arch Bridge Similar Stone Arch Bridge, Squam Lakes Natural S, White Mountains | ||
Gilsum stone arch bridge top 10 facts
The Gilsum Stone Arch Bridge carries Surry Road over the Ashuelot River in Gilsum, New Hampshire. Built in 1862-3, it is one of the highest stone-arch bridges in the state. It has a span of 47'8", and an average height over the river of 36'6". The roadway is 43'6" above the riverbed. It stands on the site of four previous bridges, where the river passes through a deep gorge. The previous bridge was also a stone-arch bridge, which was built in 1860 and collapsed (due to inferior construction) a few months later. It was designed by William Leonard Kingsbury, a local official; its builders are not known because the town's records were destroyed in a fire. The present bridge's vault is carefully constructed from dry-laid granite voussoirs that were shaped for a very precise fit, with larger stones at the lower ends of the arch, and a smaller ones at the crown. Some of the stones were left with rough surfaces, while others were hammered smooth.
In contrast to the fine stonework of the arch, the abutments and retaining walls are constructed of split-faced granite in irregular courses, wedged in place by stone chips. The northeast abutment continues along the river as a wing wall up to a massive stone pier, the former site of a mill dam. The southeast abutment is a granite reconstruction of coursed ashlar over concrete, done in 1951. The original granite coping which lined the roadway shoulders has been replaced by concrete with steel guard cables, c. 1920s.
The bridge was listed on the National Register of Historic Places in 1989.
