GOES 16

Overview

GOES-16 is a follow-on to the current GOES system that is used by NOAA's National Weather Service for weather monitoring and forecasting operations as well as by researchers for understanding interactions between land, ocean, atmosphere and climate. The GOES-R series program is a collaborative effort between NOAA and NASA to develop, deploy and operate the satellites. They are managed from Goddard Space Flight Center in Greenbelt, Maryland. The GOES-R series (GOES-R, S, T, & U) will extend the availability of the operational GOES satellite system through 2036.

GOES-16 has several improvements over the old GOES system. Its advanced instruments and data processing provides:

Spacecraft

The GOES-16 spacecraft A2100 bus is 3-axis stabilized and designed for 10 years of on-orbit operation preceded by up to 5 years of on-orbit storage. It will provide near-continuous observations as well as vibration isolation for the Earth-pointed optical bench and high-speed spacecraft-to-instrument interfaces designed to maximize data collection. The cumulative time that GOES-16 science data collection (including imaging) is interrupted by momentum management, station-keeping and yaw flip maneuvers will be under 120 minutes/year. This represents a nearly two order of magnitude improvement compared to older GOES satellites.

Instruments

The GOES-16 instrument suite includes three types of instruments: Earth sensing, solar imaging, and space environment measuring.

Earth facing

Two instruments point toward Earth:

Advanced Baseline Imager

The Advanced Baseline Imager (ABI), designed and built by Exelis Geospatial Systems (now Harris Space & Intelligence Systems), is the primary instrument on GOES-16 for imaging Earth’s weather, climate and environment. ABI will be able to view the Earth across 16 spectral bands, including two visible channels, four near-infrared channels and ten infrared channels. It will provide three times more spectral information, up to four times the spatial resolution (depending on the band), and more than five times faster coverage. Forecasters will be able to use the higher resolution images to track the development of storms in their early stages. Instruments nearly identical to ABI have been delivered to Japan for use on Himawari 8 and Himawari 9.

Geostationary Lightning Mapper

The GOES-16 Geostationary Lightning Mapper (GLM) will take continuous day and night measurements of the frequent intra-cloud lightning that accompanies many severe storms, and will do so even when the high-level cirrus clouds atop mature thunderstorms may obscure the underlying convection from the imager. Research and testing has demonstrated the GLM potential for improvement in tornado warning lead time and false alarm rate reduction. It is anticipated that GLM data will have applications to aviation weather services, climatological studies, and severe thunderstorm forecasts and warnings. The GLM will provide information to identify growing, active, and potentially destructive thunderstorms over land as well as ocean areas.

Studies show that a sudden increase in Total Lightning Activity—or flash rate—correlates with an increase in storm intensity. Thus, a significant increase in a storm's flash rate may signify a storm becoming severe and causing damaging winds, large hail, and/or tornadoes.

The GLM consists of a telescopic CCD camera sensitive to 777.4 nm light. It has a spatial resolution of 8 kilometres (5.0 mi) (at nadir) to 14 kilometres (8.7 mi) (at edge of field of view) and captures 500 frames per second. The CCD's pixel pitch varies across its area.

Sun facing

Two sun-facing instruments are mounted to the arm holding the solar panel: the Solar Ultraviolet Imager and the Extreme Ultra Violet (EUVS) / X-Ray Irradiance Sensors.

Solar Ultraviolet Imager

Solar Ultraviolet Imager (SUVI) is a telescope that observes the Sun in the extreme ultraviolet (EUV) wavelength range. SUVI will observe and characterize complex, active regions of the Sun, solar flares and the eruptions of solar filaments that may give rise to coronal mass ejections. Depending on the size and the trajectory of solar eruptions, the possible effects to the Earth’s environment, referred to as space weather, include the disruption of power utilities, communication and navigation systems and possible damage to orbiting satellites and the International Space Station. SUVI observations of flares and solar eruptions will provide an early warning of possible impacts to the Earth environment and enable better forecasting of potentially disruptive events.

Extreme Ultra Violet (EUVS) / X-Ray Irradiance Sensors

The Extreme Ultraviolet and X-Ray Irradiance Sensors (EXIS) detect solar soft X-ray irradiance and solar extreme ultraviolet spectral irradiance in the 5-127 nm range. The X-Ray Sensor (XRS) monitors solar flares that can disrupt communications and degrade navigational accuracy, affecting satellites, astronauts, high latitude airline passengers and power grid performance. The Extreme Ultraviolet Sensor monitors solar variations that directly affect satellite drag/tracking and ionospheric changes, which impact communications and navigation operations. This information is critical to understanding the outer layers of the Earth’s atmosphere.

Space environment

Two in-situ instruments will monitor the space environment: the Space Environment In-Situ Suite and a magnetometer.

Space Environment In-Situ Suite

The Space Environment In-Situ Suite (SEISS) consists of an array of sensors that will monitor the proton, electron and heavy ion fluxes at geosynchronous orbit. The data will be used for assessing radiation hazards to astronauts and satellites. In addition to hazard assessment, the data can be used to warn of high flux events, mitigating damage to radio communication. The instrument suite consists of the Energetic Heavy Ion Sensor (EHIS), the Magnetospheric Particle Sensor - High and Low (MPS-HI and MPS-LO), and the Solar and Galactic Proton Sensor (SGPS). Data will drive the solar radiation storm portion of NOAA space weather scales and other alerts and warnings and will improve solar energetic particle forecasts.

Magnetometer

The GOES-16 Magnetometer (MAG) will measure the space environment magnetic field that controls charged particle dynamics in the outer region of the magnetosphere. These particles can be dangerous to spacecraft and human spaceflight. The geomagnetic field measurements will provide alerts and warnings to satellite operators and power utilities. This data will also be used in research. Data products will be part of NOAA space weather operations, providing information on the general level of geomagnetic activity and permitting detection of sudden magnetic storms. In addition, measurements will be used to validate large-scale space environment models that are used in operations.

Unique Payload Services

The GOES-16 Unique Payload Services (UPS) consist of transponder payloads that provide communications relay services in addition to primary mission data. The UPS suite consists of the Data Collection System (DCS), the High Rate Information Transmission/Emergency Managers Weather Information Network (HRIT/EMWIN), GOES-16 Rebroadcast (GRB), and the Search and Rescue Satellite Aided Tracking (SARSAT) System.

GOES-16 Rebroadcast (GRB) is the primary space relay of Level 1b products and will replace the GOES VARiable (GVAR) service. GRB will provide full resolution, calibrated, navigated, near-real-time direct broadcast data. The data distributed via GRB service will be the full set of Level 1b products from all instruments aboard the GOES-R series spacecraft. This concept for GRB is based on analysis that a dual-pole circularly-polarized L-band link of 12 MHz bandwidth can support up to a 31-megabits per second (Mbps) data rate – enough to include all ABI channels in a lossless compressed format as well as data from GLM, SUVI, EXIS, SEISS and MAG.

The Data Collection System (DCS) is a relay system used to collect information from a large number of Earth-based platforms that transmit in-situ environmental sensor data on predefined frequencies and schedules, in response to thresholds in sensed conditions, or in response to requests. Enhancements to the DCS program during the GOES-16 era include expansion in the number of user-platform channels from 266 to 433.

The Emergency Managers Weather Information Network (EMWIN) is a direct service that provides users with weather forecasts, warnings, graphics and other information directly from the National Weather Service in near-real time. The GOES EMWIN relay service is one of a suite of methods to transmit these products to end users. The HRIT service provides broadcast of low-resolution GOES satellite imagery data and selected products to remotely located user HRIT terminals.

As an integral part of the international search and rescue satellite program called COSPAS-SARSAT, NOAA operates the Search and Rescue Satellite Aided Tracking (SARSAT) System to detect and locate mariners, aviators and other recreational users in distress almost anywhere in the world at any time and under almost any conditions. This system uses a network of satellites to detect and locate distress signals from emergency beacons onboard aircraft, vessels and from handheld personal locator beacons (PLB). The SARSAT transponder on the GOES-16 satellite will provide the capability to immediately detect distress signals from emergency beacons and relay them to ground stations - called Local User Terminals. In turn, this signal is routed to a SARSAT Mission Control Center and then sent to a Rescue Coordination Center which dispatches a search and rescue team to the location of the distress.

Ground system

NOAA is developing a ground system (GS) to receive data and generate and distribute it in real-time. The key functions of the GS are Mission Management, Product Generation, Product Distribution and Enterprise Management/Infrastructure. The ground system will operate from multiple locations:

User community

GOES-16 is preparing the satellite data user community for the coming types of imagery and data. Users include individuals, companies and institutions.

GOES-16 data is expected to appeal to a wide variety of users. Larger, institutional users can exploit the increases in spectral, temporal and spatial resolution for greater accuracy. GOES-16 data will be used in real time for life and property forecasting and warning applications primarily by the National Weather Service, where these users will be able to monitor severe storms. Other smaller public and private sector users will be able to obtain GOES-16 data through their own Earth stations, or through network distribution.

Cooperative institutes

Cooperative Institutes (CIs) are non-federal academic and non-profit research institutions supported by NOAA that provide resources to the agency's mission, goals, and strategic plans. Eight NOAA CIs support GOES-16:

Proving ground

Many GOES-16 products will be aimed at monitoring severe weather and helping forecasters issue earlier, more accurate, severe weather warnings. The Proving Ground was established to prepare operational forecasters for the amount of data that will be available with the GOES-R series and ensure maximum utilization when the satellites are launched and operational. Its goals are: training forecasters to use new products, identifying different utilities of each product, identifying weaknesses or errors with each product, user-feedback development, and day one readiness for GOES-R operations.

Launch vehicle

The GOES-16 satellite launched aboard an Atlas V 541 expendable launch vehicle from Space Launch Complex 41 at Cape Canaveral Air Force Station, Florida.
