The Wyvern began as a Westland project for a naval strike fighter, with the engine located behind the pilot, driving a propeller in the nose via a long shaft that passed under the cockpit floor, similar to the Bell P-39. This enabled the pilot to be located in a position that conferred the best possible visibility over the nose for carrier operations. Official interest resulted in Air Ministry Specification N.11/44 for a long-range naval fighter using the 24-cylinder H-block Rolls-Royce Eagle 22 piston engine (unrelated to the First World War-era engine of the same name) being issued to cover Westland's design. The specification also called for an airframe design that would be able to take a turboprop engine when a suitable unit was available. There was a parallel specification for the Royal Air Force, F.13/44, for which Hawker submitted the competing P.1027, a development of the Tempest. The RAF variant was cancelled, when in 1945 it was decided that all future fighter aircraft would be jet-powered.
The original design soon matured into the more conventional Westland W.34, with the 3,500 hp (2,610 kW) Eagle engine in the nose driving large contra-rotating propellers and the pilot sitting high in a humped fuselage to improve visibility. The design was otherwise orthodox, with a low wing, tailwheel undercarriage and double-folding wings fitted with both Youngman flaps on the inner wing section and conventional flaps on the outer section. The W.34 was to be armed with four Hispano 20 mm cannon in the wings and have the ability to carry a torpedo under the fuselage or a selection of bombs and rockets under the wings.
The prototype W.34; the Wyvern TF.1, first flew at Boscombe Down on 16 December 1946 with Westland's test pilot Harald Penrose at the controls. This aircraft was lost on 15 October 1947 when the propeller bearings failed in flight. Westland's assistant test pilot Sqn. Ldr. Peter Garner was killed attempting to make an emergency landing. From prototype number three onwards, the aircraft were navalised and carried their intended armament.
At around this time, the Eagle engine was cancelled and it was found that there were insufficient pre-production engines available to complete all the prototype and pre-production aircraft. Specification N.12/45 was therefore issued for the Wyvern TF.2, to be powered by a turboprop engine: either the Rolls-Royce Clyde or the Armstrong Siddeley Python. A single Clyde-powered prototype was ordered along with two with Pythons. A Clyde-powered TF.2 first flew on 18 January 1949. Both the piston-powered and turboprop versions shared many common components including wing and tail units, and essentially the same basic cockpit structure. The flight was cut short to only three minutes when shortly after takeoff, the cockpit filled with smoke from a fuel leak onto the exhaust ducting. Clyde development was subsequently cancelled by Rolls-Royce after only 50 hours of flight time for the TF.2, and the aircraft was delivered to Napier & Son to be fitted with the Nomad turbo-compound engine. The latter engine never materialised, however and this aircraft was used for crash barrier trials.
The first Python-powered TF.2 flew on 22 March 1949 and this aircraft introduced the ejection seat to the Wyvern. Twenty TF.2s were completed to the Python design although after three years of testing what was then a revolutionary aircraft design, a myriad of detailed aerodynamic changes resulted. The Python engine responded poorly to minor throttle adjustments, so control was exercised by running the engine at a constant speed and varying the pitch of the propellers. The aircraft was declared ready for service in 1952, but never reached an operational squadron.
The definitive Wyvern model was the TF.4, later S.4. Initially, 50 S.4s were ordered and were joined by the last 7 TF.2s, which were altered while still under construction. S.4s reached limited shore-based front line service in May 1953 with 813 Naval Air Squadron at RNAS Ford, replacing the somewhat similar (and equally troubled) Blackburn Firebrand. Several second-line squadrons also received Wyverns around this time.
Total production was 127 airframes with 124 aircraft completed, as the last three Eagle piston-engined airframes, VR138, -139, and -140, were never completed.
The first carrier trials were carried out by the first pre-production Wyvern TF.2 aboard HMS Illustrious on 21 June 1950. Despite this, when the Wyvern S.4 entered service with 813 Naval Air Squadron in May 1953, it had not obtained clearance for carrier operations, this being obtained only in April 1954. The Wyvern was in service with the Fleet Air Arm from 1954 to 1958. Wyverns equipped 813 Squadron, 827 Squadron, 830 Squadron and 831 Squadron of the Fleet Air Arm.
In September 1954, 813 embarked with their Wyverns on HMS Albion for carrier-based service in the Mediterranean. The Wyvern soon showed a worrying habit for flameout on catapult launch; the high G forces resulting in fuel starvation. A number of aircraft were lost off Albion's bows and Lt. B. D. Macfarlane made history when he successfully ejected from under water after his aircraft had ditched on launch and been cut in two by the carrier. 813 did not return to Albion until March 1955 when the problems had been resolved.
830 Sqn. took the Wyvern into combat from HMS Eagle, flying 79 sorties during Operation Musketeer; the armed response to the Suez Crisis. Two Wyverns were lost to damage from Egyptian light anti-aircraft fire; both pilots of the aircraft successfully ejected over the sea, and were picked up by Eagle's search and rescue helicopter. The squadron returned to the UK on Eagle after this conflict and disbanded in January 1957. Consequently, 813 was the last Wyvern squadron, disbanding on 22 April 1958.
All Wyverns were withdrawn from service by 1958: while in service and testing there were 68 accidents, 39 were lost and there were 13 fatalities; including two RAF pilots and one US Navy pilot.
Six prototypes ordered in August 1944, with the first aircraft flown 12 December 1946.
Pre-production aircraft ordered in June 1946, with only seven built of 20 contracted.
The original production version. Three prototypes were ordered in February 1946 with a production contract for 20 aircraft issued in September 1947. Only nine production aircraft were built, and the remaining eleven were completed as S.4s.
Two-seat conversion trainer. One prototype serialed VZ739 was ordered in September 1948 and first flown in February 1950.
The definitive version. 50 were ordered in October 1948, 13 in December 1950, 13 in January 1951 and a final 11 in February 1951. A total of 98 built (including 11 that had started as TF.2s). The model was later redesignated as the S.4
An unflown pre-production aircraft, the last to be fitted with the original Eagle piston engine, (serial number VR137) is on display at the Fleet Air Arm Museum in Yeovilton, England.
Royal Navy Fleet Air Arm700 Naval Air Squadron
703 Naval Air Squadron
764 Naval Air Squadron
787 Naval Air Squadron
813 Naval Air Squadron
827 Naval Air Squadron
830 Naval Air Squadron
831 Naval Air Squadron
Wyvern Conversion Unit at Royal Naval Air Station Ford
Data from Westland Aircraft since 1915
General characteristicsCrew: 1 (2 in T.3)
Length: 42 ft 3 in (12.88 m)
Wingspan: 44 ft 0 in (13.41 m) (folded 20 ft (6 m)
Height: 15 ft 9 in (4.80 m) (folded 20 ft (6 m)
Wing area: 355 sq ft (33.0 m2)
Empty weight: 15,600 lb (7,076 kg)
Gross weight: 21,200 lb (9,616 kg)
Max takeoff weight: 24,550 lb (11,136 kg)
Powerplant: 1 × Armstrong Siddeley Python turboprop engine, 3,560 hp (2,650 kW) +1,100 lbf (4.893 kN) residual thrust
Propellers: 4-bladed Rotol contra-rotating, 13 ft (4.0 m) diameter
PerformanceMaximum speed: 383 mph (616 km/h; 333 kn) at sea level, 380 mph (612 km/h) at 10,000 ft (3,048 m)
Range: 910 mi (791 nmi; 1,465 km)
Service ceiling: 28,000 ft (8,500 m)
Rate of climb: 2,350 ft/min (11.9 m/s)
Wing loading: 59.7 lb/sq ft (291 kg/m2)
Power/mass: 0.194 eshp/lb
ArmamentGuns: 4 × 20mm British Hispano Mk.V cannon, 2 in each wing
Rockets: 16 × RP-3 underwing rockets
Missiles: 1 × Mk.15 or Mk.17 torpedo
Bombs: Up to 3,000 lb (1,361 kg) of bombs or mines
