Jabiru J250

Updated on
Edit
Like
Comment
Share on FacebookTweet on TwitterShare on LinkedInShare on Reddit
Top speed

256 km/h

Manufacturer

Jabiru Aircraft

Length

6.53 m

Jabiru J250 J250450 Experimental Aircraft Jabiru Light Sport amp Experimental

Jabiru j250 flight to grant county airport


The Jabiru J250 is one model in a large family of two and four seat Australian light aircraft developed as touring aircraft and provided in kit form by Jabiru Aircraft. The aircraft was also assembled and sold in the US by Jabiru USA as a Light Sport Aircraft (LSA).

Contents

Jabiru J250 J250 Specifications A photo

Jabiru j250


Design and development

Jabiru J250 Jabiru J250 Specifications A photo

The J250 is constructed from composite materials. The 30 ft (9.1 m) span high wing is strut-braced. The standard engine is the 120 hp (89 kW) Jabiru 3300 six cylinder, horizontally opposed, four stroke aircraft engine. The tricycle landing gear has optional wheel pants. The two-seat cabin features a width of 44 in (112 cm). The J250 shares the same fuselage as the four-seat J450 model, the difference being that the rear seats are not installed on the J250. As a result, the baggage area in the J250 is among the largest in its class.

Variants

data from Jabiru

Jabiru J250 Vast Aviation LLC 2007 Jabiru J250 E Light Sport
Jabiru J160
Jabiru J170
US light-sport aircraft two-seat model derived from the J160.
Jabiru J200
Jabiru J230
A two-seater, designed as a US light-sport aircraft, with a large baggage compartment behind the seats.
Jabiru J250
Jabiru J400
Four seat version powered by a 120 hp (89 kW) Jabiru 3300 engine and marketed circa 2004.
Jabiru J430
A four seater version of the J230 with two seats in the former baggage compartment.
Jabiru J250 Jabiru J250 Untitled Aviation Photo 2240724 Airlinersnet
Jabiru J450
Jabiru SP
Two seat version for the US light-sport aircraft market, powered by a 120 hp (89 kW) Jabiru 3300 engine and marketed circa 2004. The SP has a cruise speed of 213 km/h (132 mph)
Jabiru UL
Two seat version for the European microlight category powered by a 80 hp (60 kW) Jabiru 2200 engine and marketed circa 2004. The SP has a cruise speed of 185 km/h (115 mph)

Specifications (J250)

Data from Jabiru Pacific

General characteristics


  • Crew: 2
  • Length: 21 ft 5in ()
  • Wingspan: 30 ft ()
  • Height: 7 ft 10 in ()
  • Wing area: 120 sq ft ()
  • Empty weight: 840 lb ()
  • Useful load: 480 lb ()
  • Max. takeoff weight: 1,320 lb ()
  • Powerplant: 1 × Jabiru 3300 6 cylinder, 4 stroke piston engine, 120hp ()
  • Propellers: 2-bladed Wooden/Composite propeller, 1 per engine

    • Performance


  • Never exceed speed: 138 kn
  • Maximum speed: 138 kn
  • Cruise speed: 120 kn
  • Stall speed: 45 kn ()
  • Range: 920 mi ()
  • Service ceiling: 15,000 ft ()
  • Rate of climb: 1,000 ft/min ()
  • Wing loading: 11.0 lbf/(sq ft) ()
