Power type Diesel-hydraulic Total produced 43 Gauge 1,067 mm (3 ft 6 in) | Build date 1961-1979 UIC class Bo-Bo | |
 | ||
Builder Kisha Seizo, Kawasaki Heavy Industries | ||
The Class DD14 (DD14形) was a Bo-Bo wheel arrangement diesel-hydraulic locomotive type operated in Japan as a self-propelled rotary snowplough unit from 1961 to 2015 by the national railway company Japanese National Railways (JNR), and later by East Japan Railway Company (JR East). West Japan Railway Company (JR West), and Hokkaido Railway Company (JR Hokkaido).
Contents
Design
Based on the earlier Class DD13 6th-batch locomotives, the Class DD14 was a single-end-cab design with a rotary snowplough unit at the cab end. It was the first diesel-powered rotary snowplough built by JNR. The locomotives had two 500 hp (370 kW) diesel engines. One engine could be used for propulsion with the other driving the rotary snowplough unit, giving a snow-clearing capacity of approximately 3,000 tonnes per hour, or the unit could be operated in multiple with a second locomotive allowing both engines to drive the rotary snowplough, giving a snow-clearing capacity of approximately 4,000 tonnes per hour.
Variants
History
By 2005, only nine locomotives remained in service, all operated by JR East. The last remaining locomotives in service, DD14 327 and 332, based at JR East's Nagaoka Depot, made their final run on 24 February 2014.
Preserved examples
As of 2012, three Class DD14 locomotives are preserved in Japan, with one locomotive sold to Taiwan High Speed Rail (THSR) in Taiwan.
Related classes
Classification
The DD14 classification for this locomotive type is explained below.
