Fallout shelter

History

During the Cold War, many countries built fallout shelters for high-ranking government officials and crucial military facilities, such as Project Greek Island and Cheyenne Mountain nuclear bunker in the United States and Canada's Emergency Government Headquarters. Plans were made, however, to use existing buildings with sturdy below-ground-level basements as makeshift fallout shelters. These buildings were usually placarded with the yellow and black trefoil sign.

The National Emergency Alarm Repeater (NEAR) program was developed in the United States 1956 during the Cold War to supplement the existing siren warning systems and radio broadcasts in the event of a nuclear attack. The N.E.A.R. civilian alarm device was engineered and tested but the program was not viable and was terminated in 1967. In the U.S. in September 1961, under the direction of Steuart L. Pittman, the federal government started the Community Fallout Shelter Program. A letter from President Kennedy advising the use of fallout shelters appeared in the September 1961 issue of Life magazine.

In November 1961, in Fortune magazine, an article by Gilbert Burck appeared that outlined the plans of Nelson Rockefeller, Edward Teller, Herman Kahn, and Chet Holifield for an enormous network of concrete lined underground fallout shelters throughout the United States sufficient to shelter millions of people to serve as a refuge in case of nuclear war.

Similar projects have been undertaken in Finland, which requires all buildings with area over 600 m² to have an NBC shelter, and Norway, which requires all buildings with an area over 1000 m² to have a shelter.

The former Soviet Union and other Eastern Bloc countries often designed their underground mass-transit and subway tunnels to serve as bomb and fallout shelters in the event of an attack.

Germany has protected shelters for 3% of its population, Austria for 30%, Finland for 70%, Sweden for 81% and Switzerland for 114%.

Switzerland

Switzerland built an extensive network of fallout shelters, not only through extra hardening of government buildings such as schools, but also through a building regulation requiring nuclear shelters in residential buildings since the 1960s (the first legal basis in this sense dates from 4 October 1963). Later, the law ensured that all residential buildings built after 1978 contained a nuclear shelter able to withstand a blast from a 12 megaton explosion at a distance of 700 metres. The Federal Law on the Protection of the Population and Civil Protection still requires nowadays that every inhabitant should have a place in a shelter close to where they live.

The Swiss authorities also maintain large communal shelters (such as the Sonnenberg Tunnel) stocked with over four months of food and fuel. The reference Nuclear War Survival Skills declared that, as of 1986, "Switzerland has the best civil defense system, one that already includes blast shelters for over 85 percent of all its citizens." As of 2006, there were about 300,000 shelters built in private homes, institutions and hospitals, as well as 5,100 public shelters for a total of 8.6 million places, a level of coverage equal to 114% of the population.

In Switzerland, most residential shelters are no longer stocked with the food and water required for prolonged habitation and a large number have been converted by the owners to other uses (e.g., wine cellars, ski rooms, gyms). But the owner still has the obligation to ensure the maintenance of the shelter.

Shielding

A basic fallout shelter consists of shields that reduce gamma ray exposure by a factor of 1000. The required shielding can be accomplished with 10 times the thickness of any quantity of material capable of cutting gamma ray exposure in half. Shields that reduce gamma ray intensity by 50% (1/2) include 1 cm (0.4 inch) of lead, 6 cm (2.4 inches) of concrete, 9 cm (3.6 inches) of packed earth or 150 m (500 ft) of air. When multiple thicknesses are built, the shielding multiplies. Thus, a practical fallout shield is ten halving-thicknesses of packed earth, reducing gamma rays by approximately 1024 times (2¹⁰).

Usually, an expedient purpose-built fallout shelter is a trench; with a strong roof buried by c. 1 m (3 ft) of earth. The two ends of the trench have ramps or entrances at right angles to the trench, so that gamma rays cannot enter (they can travel only in straight lines). To make the overburden waterproof (in case of rain), a plastic sheet may be buried a few inches below the surface and held down with rocks or bricks.

Blast doors are designed to absorb the shock wave of a nuclear blast, bending and then returning to their original shape.

Climate control

Dry earth is a reasonably good thermal insulator, and over several weeks of habitation, a shelter will become dangerously hot. The simplest form of effective fan to cool a shelter is a wide, heavy frame with flaps that swing in the shelter's doorway and can be swung from hinges on the ceiling. The flaps open in one direction and close in the other, pumping air. (This is a Kearny Air Pump, or KAP, named after the inventor, Cresson Kearny)

Unfiltered air is safe, since the most dangerous fallout has the consistency of sand or finely ground pumice. Such large particles are not easily ingested into the soft tissues of the body, so extensive filters are not required. Any exposure to fine dust is far less hazardous than exposure to the fallout outside the shelter. Dust fine enough to pass the entrance will probably pass through the shelter. Some shelters, however, incorporate NBC-filters for additional protection.

Locations

Effective public shelters can be the middle floors of some tall buildings or parking structures, or below ground level in most buildings with more than 10 floors. The thickness of the upper floors must form an effective shield, and the windows of the sheltered area must not view fallout-covered ground that is closer than 1.5 km (1 mi). One of Switzerland's solutions is to utilise road tunnels passing through the mountains, with some of these shelters being able to protect tens of thousands.

Fallout shelters are not always underground. Above ground buildings with walls and roofs dense enough to afford a meaningful protection factor can be used as a fallout shelter.

Contents

A battery-powered radio may be helpful to get reports of fallout patterns and clearance. However, radio and other electronic equipment may be disabled by electromagnetic pulse. For example, even at the height of the cold war, EMP protection had been completed for only 125 of the approximately 2,771 radio stations in the United States Emergency Broadcast System. Also, only 110 of 3,000 existing Emergency Operating Centers had been protected against EMP effects. The Emergency Broadcast System has since been supplanted in the United States by the Emergency Alert System.

The reference Nuclear War Survival Skills includes the following supplies in a list of "Minimum Pre-Crisis Preparations": one or more shovels, a pick, a bow-saw with an extra blade, a hammer, and 4-mil polyethylene film (also any necessary nails, wire, etc.); a homemade shelter-ventilating pump (a KAP); large containers for water; a plastic bottle of sodium hypochlorite bleach; one or two KFMs and the knowledge to operate them; at least a 2-week supply of compact, nonperishable food; an efficient portable stove; wooden matches in a waterproof container; essential containers and utensils for storing, transporting, and cooking food; a hose-vented 5-gallon can, with heavy plastic bags for liners, for use as a toilet; tampons; insect screen and fly bait; any special medications needed by family members; pure potassium iodide, a 2-oz bottle, and a medicine dropper; a first-aid kit and a tube of antibiotic ointment; long-burning candles (with small wicks) sufficient for at least 14 nights; an oil lamp; a flashlight and extra batteries; and a transistor radio with extra batteries and a metal box to protect it from electromagnetic pulse.

Inhabitants should have water on hand, 1-2 gallons per person per day. Water stored in bulk containers requires less space than water stored in smaller bottles.

Kearny fallout meter

Commercially made Geiger counters are expensive and require frequent calibration. It is possible to construct an electrometer-type radiation meter called the Kearny fallout meter, which does not require batteries or professional calibration, from properly-scaled plans with just a coffee can or pail, gypsum board, monofilament fishing line, and aluminum foil. Plans are freely available in the public domain in the reference Nuclear War Survival Skills by Cresson Kearny.

Use

Inhabitants should plan to remain sheltered for at least two weeks (with an hour out at the end of the first week – see Swiss Civil Defense guidelines (which was once part of Swiss Zivilschutz)), then work outside for gradually increasing amounts of time, to four hours a day at three weeks. The normal work is to sweep or wash fallout into shallow trenches to decontaminate the area. They should sleep in a shelter for several months. Evacuation at three weeks is recommended by official authorities.

If available, inhabitants may take potassium iodide at the rate of 130 mg/day per adult (65 mg/day per child) as an additional measure to protect the thyroid gland from the uptake of dangerous radioactive iodine, a component of most fallout and reactor waste.

Alpha (α)

In the vast majority of accidents, and in all atomic bomb blasts, the threat due to beta and gamma emitters is greater than that posed by the alpha emitters in the fallout. Alpha particles are identical to a helium-4 nucleus (two protons and two neutrons), and travel at speeds in excess of 5% of the speed of light. Alpha particles have little penetrating power; most cannot penetrate through human skin. Avoiding direct exposure with fallout particles will prevent injury from alpha radiation.

Beta (β)

Beta radiation consists of particles (high-speed electrons) given off by some fallout. Most beta particles cannot penetrate more than about 10 feet (3 metres) of air or about  ¹⁄₈ inch (3 millimetres) of water, wood, or human body tissue; or a sheet of aluminum foil. Avoiding direct exposure with fallout particles will prevent most injuries from beta radiation.

The primary dangers associated with beta radiation are internal exposure from ingested fallout particles and beta burns from fallout particles no more than a few days old. Beta burns can result from contact with highly radioactive particles on bare skin; ordinary clothing separating fresh fallout particles from the skin can provide significant shielding.

Gamma (γ)

Gamma radiation penetrates further through matter than alpha or beta radiation. Most of the design of a typical fallout shelter is intended to protect against gamma rays. Gamma rays are better absorbed by materials with high atomic numbers and high density, although neither effect is important compared to the total mass per area in the path of the gamma ray. Thus, lead is only modestly better as a gamma shield than an equal mass of another shielding material such as aluminum, concrete, water or soil.

Some gamma radiation from fallout will penetrate into even the best shelters. However, the radiation dose received while inside a shelter can be significantly reduced with proper shielding. Ten halving thicknesses of a given material can reduce gamma exposure to less than  ¹⁄₁₀₀₀ of unshielded exposure.

Weapons versus nuclear accident fallout

The bulk of the radioactivity in nuclear accident fallout is more long-lived than that in weapons fallout. A good table of the nuclides, such as that provided by the Korean Atomic Energy Research Institute, includes the fission yields of the different nuclides. From this data it is possible to calculate the isotopic mixture in the fallout (due to fission products in bomb fallout).

Other matters and simple improvements

While a person's home may not be a purpose-made shelter, it could be thought of as one if measures are taken to improve the degree of fallout protection.

Measures to lower the beta dose

The main threat of beta radiation exposure comes from hot particles in contact with or close to the skin of a person. Also, swallowed or inhaled hot particles could cause beta burns. As it is important to avoid bringing hot particles into the shelter, one option is to remove one's outer clothing, or follow other decontamination procedures, on entry. Fallout particles will cease to be radioactive enough to cause beta burns within a few days following a nuclear explosion. The danger of gamma radiation will persist for far longer than the threat of beta burns in areas with heavy fallout exposure.

Measures to lower the gamma dose rate

The gamma dose rate due to the contamination brought into the shelter on the clothing of a person is likely to be small (by wartime standards) compared to gamma radiation that penetrates through the walls of the shelter. The following measures can be taken to reduce the amount of gamma radiation entering the shelter:

Fallout shelters in popular culture

Fallout shelters feature prominently in the Robert A. Heinlein novel Farnham's Freehold (Heinlein built a fairly extensive shelter near his home in Colorado Springs in 1963), Pulling Through by Dean Ing, A Canticle for Leibowitz by Walter M. Miller and Earth by David Brin.

The Twilight Zone episode "The Shelter", from a Rod Serling script, deals with the consequences of actually using a shelter.

In the Only Fools and Horses episode "The Russians are Coming", Derek Trotter buys a lead fallout shelter, then decides to construct it in fear of an impending nuclear war caused by the Soviet Union (who were still active during the episode's creation).

In 1999 the film Blast from the Past was released. It is a romantic comedy film about a nuclear physicist, his wife, and son that enter a well-equipped, spacious fallout shelter during the 1962 Cuban Missile Crisis. They do not emerge until 35 years later, in 1997. The film shows their reaction to contemporary society.

The Fallout series of computer games depicts the remains of human civilization after an immensely destructive global nuclear war; the United States of America had built underground vaults that were advertised to protect the population against a nuclear attack, but almost all of them were in fact meant to lure subjects for long-term human experimentation.

Fallout Shelter is a free-to-play mobile simulation video game developed by Bethesda Game Studios and published by Bethesda Softworks. Part of the Fallout series, it was released for iOS devices on June 14, 2015, and was released for Android devices on August, 13 2015.

Paranoia, a role-playing game, takes place in a form of fallout shelter, which has become ruled by an insane computer.

The Metro 2033 book series by Russian author Dmitry Glukhovsky depicts survivors' life in the subway systems below Moscow and Saint-Petersburg after a nuclear exchange between the Russian Federation and the United States of America.

Fallout shelters are often featured on the reality television show Doomsday Preppers.

The Silo series of novellas by Hugh Howey feature extensive fallout-style shelters that protect the inhabitants from an initially unknown disaster.
