Country Portugal Status Operational Surface area 12.98 km² Construction began 1976 | Purpose Power Opening date 1985 Operator Energias de Portugal Impound Douro | |
 | ||
Official name Barragem de Crestuma-Lever Location municipality Vila Nova de Gaia, Porto District Similar Douro, Carrapatelo Dam, Valeira Dam, Régua Dam, Pocinho Dam | ||
Douro river crestuma lever dam viking hemming
Crestuma-Lever Dam (Portuguese: Barragem de Crestuma-Lever) is a concrete gravity dam on the Douro. It is located in the municipality Vila Nova de Gaia, in Porto District, Portugal.
Contents
Construction of the dam began in 1976. The dam was completed in 1985. It is owned by Companhia Portuguesa de Produção de Electricidade (CPPE).
DamEdit
Crestuma-Lever Dam is a 25.5 m tall (height above foundation) and 470 m long gravity dam with a crest altitude of 25.5 m. The volume of the dam is 205,000 m³. The spillway with 8 gates is part of the dam body (maximum discharge 26,000 m³/s).
ReservoirEdit
At full reservoir level of 13 m (maximum flood level of 21.5 m) the reservoir of the dam has a surface area of 12.98 km² and a total capacity of 110 mio. m³. The active capacity is 22.5 (16 or 19) mio. m³.
Power plantEdit
The run-of-the-river hydroelectric power plant was commissioned in 1985 (1986). It is operated by EDP. The plant has a nameplate capacity of 117 (105 or 108) MW. Its average annual generation is 360 (311, 363, 366.9, or 399) GWh.
The power station contains 3 Kaplan turbine-generators (horizontal axis) with 39 (36) MW (36.1 MVA) each in a dam powerhouse located on the left side of the dam. The turbine rotation is 83.3 rpm. The minimum hydraulic head is 6.8 m, the maximum 12.6 m. Maximum flow per turbine is 450 m³/s.
The turbines and generators were provided by Sorefame.
LockEdit
On the left side of the dam is a lock, which can handle ships with the following maximum properties: 83 m in length, 11.40 m on the beam, 3.8 m load-draught and a cargo capacity of 2500 tons.
