Wavefront Technology Solutions

History

Wavefront Technology Solutions Inc., was founded in 1997 under the name PE-TECH Inc. (Pulse Enhancement Technology Inc.). PE-TECH, a privately held company holding intellectual property operated three subsidiaries; Prism Production Technologies Inc., Wavefront Environmental Technologies Inc., and E2 Solutions Inc. (US subsidiary standing for "Energy and Environmental"). In 2000 the shareholders of the privately held PE-TECH Inc., entered into an agreement with a publicly listed company (or in this case a shell of a company) on the TSX Venture Exchange.

A reverse takeover of that entity transformed PE-TECH Inc., from a privately held company to a publicly traded company under the name Wavefront Energy and Environmental Services Inc. For consistency in name branding Prism Production Technologies was renamed Wavefront Reservoir Technologies Inc., Wavefront Environmental Technologies was rolled into Wavefront Reservoir Technologies Inc. and E2 Solutions Inc. was renamed Wavefront Energy and Environmental Services USA Inc. Effective March 27, 2009 the company’s name was changed to “Wavefront Technology Solutions Inc.”

Rationale

Brett Davidson and University of Alberta professor Tim Spanos teamed up in 1997 to fulfill a need that they believed to exist in the onshore oil drilling industry. While working on oil well stimulation site in Alberta, Canada, Davidson heard from a friend in the industry that there was a need for fast, effective, and inexpensive stimulation treatment for oil wells.

After using the most sophisticated oil recovery techniques, oil companies only retrieve a fraction of the crude oil at their sites. The oil well will become too uneconomical to continue pumping because most of the remaining oil is stuck in the nooks and crannies between the rock and sand.

Even after all work is done, around 60% of oil is left in the ground. With more than 200,000 fields in North America alone, extracting even as little as 10% more oil would translate to billions of more barrels of oil recovered.

Primary Oil Recovery Stage

During primary recovery, the natural pressure of the reservoir or gravity drive oil into the wellbore, combined with artificial lift techniques (such as pumps) which bring the oil to the surface. But only about 10 percent of a reservoir's original oil in place is typically produced during primary recovery.

But petroleum isn’t the only thing trapped in the earth. Water hides there too. Sooner or later, the reservoir begins producing water, along with oil, and it becomes uneconomical to continue. The oil companies will then re-inject the water back into the reservoir. This stage of production is called secondary recovery.

Secondary Oil Recovery Stage

Water injection helps maintain downhole pressure so that oil can continue to flow. Water from the injection well is also used to sweep or push the oil towards the producing wells. But rock in the reservoir has varying permeabilities; the more permeable the rock is, the more easily the fluid can flow through.

Unfortunately, water flows more readily than oil, and it always takes the path of least resistance. Once water creates a channel through the permeable rock to the producing wellbore, there is little benefit in injecting additional water. It only bypasses the oil instead of sweeping it ahead. The result is poor recovery from the reservoir.

Products and Technologies

Wavefront Technology Solutions's patented technology was created to combat the “path of least resistance”. In this way, the Powerwave and the Primawave share the same scientific principles. This technology, originally penned as "Power Pulse Technology", uses pulses to improve the liquid flow in the ground for improved oil recovery (IOR) in the energy sector and groundwater remediation in the environmental sector. These identical processes generate a fluid pulse that momentarily expands the pore structure of rock and soil. Liquid is then able to flow freely and more uniformly.

Early iterations of Wavefront Technology Solutions's Power Pulse Technology were penned the “Premier Pulse Tool”. The Premier Pulse Tool, or PPT for short, was a two-meter long steel mandrel with a valve system on top and inverted swab cups on the bottom.

Using a standard well servicing rig, the PPT would be lowered to a location above the well perforations. The tool would then be raised up eight meters and dropped. This was done between 200-550 times over eight to 12 hours.

This workover and field stimulation technique used steady, non-seismic pulse vibrations to knock out perforation blockage and create a tsunami-like wave effect that encouraged flow in the reservoir.

This technology, utilized in both the Powerwave and Primawave, generates a fluid pressure pulse that causes a momentary elastic flexure of the pore structure. This pressure pulse moves fluid in and out of a larger number of pore networks, obtaining a more uniform injection front.

Powerwave

In the energy sector, Wavefront Technology Solutions Inc. has patented the Power Pulse Technology as “Powerwave.” This process has been field-tested and proven to increase the amount of oil recovered from on shore oil wells, including low-producing or even abandoned fields. Powerwave utilizes this technology to improve the flow of water through geological materials, including sedimentary soils and fractured rock. These materials are composed of a solid matrix and pore structure, which contain fluids such as gas and oil.

The Powerwave tool generates a fluid displacement wave in the porous media akin to ripples from a stone thrown in a pond. These ripples generate high liquid accelerations in the pores facing liquids out, or treatment fluids in.

In the ten plus years that the technology behind Powerwave has been developed by Wavefront Technologies and Environmental Services, it has evolved from a product that cost nearly $1 to make and had to be transported using two tractor trailers to one that can be shipped via courier. The Powerwave tool now is only one meter high and eight centimeters in diameter. Wavefront Technology Solutions Inc. leases the product to oil companies and charges around $3,000 a month for a minimum 12-month period.

Powerwave’s ability to improve uniformity in oil wells has translated to higher production rates, extending the life of a field, and enhancing its value. In Texas, one recent field trial raised production rates from eight wells by 26%. A similar project in Alberta, Canada initially raised output by 18%.

Primawave

In the environmental sector, Wavefront Technology Solutions Inc. has patented the Power Pulse Technology as “Primawave.” Primawave is used largely in the United States. It is licensed to service providers to use the process in conjunction with established methods to treat and eliminate hazardous chemicals from contaminated groundwater.

NASA once used Primawave to clean up soil that had been contaminated with tetrachloroethylene (dry-cleaning fluid). In the 1960s NASA had used the hazardous chemical to remove the soot generated by rockets from the launch site.

Years after using the chemical, the area was saturated with carcinogens. NASA knew that a mixture including iron fillings would decontaminate the soil. NASA then used the Primawave to get the fillings into the ground.
