Formula C6H6N6O6 Density 1.93 g/cm³ Shock sensitivity Insensitive | Molar mass 258.15 g/mol Detonation velocity 7350 m/s Friction sensitivity Insensitive | |
 | ||
Appearance Yellow or brown powdered crystals (rhombohedral) | ||
Pbx 9502 tatb based plastic bonded explosive
TATB, triaminotrinitrobenzene or 2,4,6-triamino-1,3,5- trinitrobenzene is an aromatic explosive, based on the basic six-carbon benzene ring structure with three nitro functional groups (NO2) and three amine (NH2) groups attached, alternating around the ring.
Contents
TATB is a powerful explosive (somewhat less powerful than RDX, but more than TNT), but it is extremely insensitive to shock, vibration, fire, or impact. Because it is so difficult to detonate by accident, even under severe conditions, it has become preferred for applications where extreme safety is required, such as the explosives used in nuclear weapons, where accidental detonation during an airplane crash or rocket misfiring would present extreme dangers. All British nuclear warheads, except those where weight is a factor, are believed to use TATB-based explosives for main explosive charges. According to David Albright, South Africa's nuclear weapons used TATB to increase their safety.
TATB is normally used as the explosive ingredient in plastic bonded explosive compositions, such as PBX-9502, LX-17-0, and PBX-9503 (with 15% HMX). These formulations are described as Insensitive High Explosives or IHE in nuclear weapons literature.
Though it could theoretically be mixed with other explosive compounds in castable mixtures or other use forms, the applications for such forms would be unclear since they would largely undo the insensitivity of pure TATB.
TATB's chemical structure is somewhat similar to the powerful experimental insensitive high explosive FOX-7.
Tatb powder
Properties
At a pressed density of 1.80, TATB has a velocity of detonation of 7,350 meters per second.
TATB has a crystal density of 1.93 grams/cm3, though most use forms have no higher density than 1.80. TATB melts at 350 °C. The chemical formula for TATB is C6(NO2)3(NH2)3.
TATB is a bright yellow color.
TATB has been found to remain stable at temperatures at least as high as 250 °C for prolonged periods of time.
Production
TATB is produced by nitration of 1,3,5-trichlorobenzene to 1,3,5-trichloro-2,4,6-trinitrobenzene, then the chlorine atoms are substituted with amine groups.
However, it is likely that the production of TATB will be switched over to a process involving the nitration and transamination of phloroglucinol, since this process is milder, cheaper, and reduces the amount of ammonium chloride salt produced in waste effluents (greener).
Still another process has been found for the production of TATB from materials that are surplus to military use. 1,1,1-trimethylhydrazinium iodide (TMHI) is formed from the rocket fuel unsymmetrical dimethylhydrazine (UDMH) and methyl iodide, and acts as a vicarious nucleophilic substitution (VNS) amination reagent. When Picramide, which is easily produced from Explosive D, is reacted with TMHI it is aminated to TATB. Thus, materials that would have had to have been destroyed when no longer needed are converted into a high value explosive.
