Six Chuter SR7

Design and development

The SR7's design goals included that it be capable of carrying large-sized pilots and passengers.

The aircraft was designed to comply with the US FAR 103 Ultralight Vehicles rules as a two-seat ultralight trainer or as an amateur built. It features a parachute-style high-wing, two-seats-in-tandem, tricycle landing gear and a single 64 hp (48 kW) Rotax 582 engine in pusher configuration.

The SR7 is built from a combination of aluminium and 4130 steel tubing. In flight steering is accomplished via foot pedals that actuate the canopy brakes, creating roll and yaw. On the ground the aircraft has lever-controlled nosewheel steering. The SR7 model was factory supplied in the form of an assembly kit that requires 40 hours to complete.

Variants

SR7

Base model with the 64 hp (48 kW) Rotax 582 engine.

SR7XL

Upgraded model with SR7 options included as standard.

Power Hawk

Similar to the SR7, but came fully assembled.

Discovery

Based on the SR7, but with a fiberglass enclosure. Provided fully assembled.

Specifications (XR7XL)

Data from KitPlanes

General characteristics

Crew: one

Capacity: one passenger

Length: 8 ft 6 in (2.59 m)

Wingspan: 39 ft 6 in (12.04 m)

Height: 7 ft 0 in (2.13 m)

Wing area: 500 sq ft (46 m²)

Empty weight: 299 lb (136 kg)

Gross weight: 700 lb (318 kg)

Fuel capacity: 10 U.S. gallons (38 L; 8.3 imp gal)

Powerplant: 1 × Rotax 582 twin cylinder, two-stroke, liquid-cooled aircraft engine, 64 hp (48 kW)

Performance

Cruise speed: 26 mph (42 km/h; 23 kn)

Range: 50 mi (43 nmi; 80 km)

Service ceiling: 10,000 ft (3,000 m)

Rate of climb: 500 ft/min (2.5 m/s)
