Schempp Hirth Ventus

Updated on
Edit
Like
Comment
Share on FacebookTweet on TwitterShare on LinkedInShare on Reddit
Top speed

250 km/h

Wingspan

18 m

Designer

Length

6.58 m

Manufacturer

Schempp-Hirth Ventus wwwaviatornlimagesDDKFGW20070804APICT0252

Schempp hirth ventus ct accident ueffeln


The Schempp-Hirth Ventus is a sailplane produced during 1980-1994 by Schempp-Hirth, a German sailplane manufacturer. It was designed by Klaus Holighaus and replaced the Schempp-Hirth Mini-Nimbus. Schempp-Hirth manufactured 613 Ventus sailplanes.

Contents

Schempp-Hirth Ventus SchemppHirth Ventus Photos AirplanePicturesnet

Schempp hirth ventus 2c 6m scale 1 3 start und landung


Design and Development

Schempp-Hirth Ventus SCHEMPPHIRTH Flugzeugbau GmbH Designed by Klaus Holighaus 19641994

The decline in the cost of carbon fibre during the 1970s allowed sailplane designers to design large components from carbon-fibre reinforced plastic (CFRP). The use of carbon-fibre lay-ups, designed to reduce aero-elasticity of wings, has allowed CFRP gliders to be designed to cruise at much higher speeds than those with wings made from fibreglass (GFRP) or wood, as well as take advantage of thinner aerofoil sections. The Ventus has a 15 metre wingspan, using CFRP in its structure, complying with 15m Racing Class specifications. Extended wingtips can be fitted to increase the span to 16.6 metres for competition in the Open Class. The fuselage was also produced in two sizes to suit pilots of different heights - the Ventus A for short pilots and Ventus B with a longer and wider cockpit. Both Ventus A and Ventus B have a complex flap/brake arrangement similar to that of the Glasflügel Mosquito and the Mini-Nimbus, but the Ventus C reverted to conventional upper-surface air-brakes that are separate from the trailing-edge flaps.

Schempp-Hirth Ventus SchemppHirth Ventus 2cxa Untitled Aviation Photo 1890225

Wingtip extensions could be fitted to the Ventus A and B to increase the wingspan to 16.6 m. Longer extensions could be fitted to the Ventus C to increase the span to 17.6m. Modified extensions with winglets are also available. Some Ventus Bs and Cs are equipped with a small sustaining engine ("turbo") and are designated with a T while some are equipped with a more powerful engine and are self-launching and are designated with an M.

Schempp-Hirth Ventus saleplane SchemppHirth Ventus pilots aviation flying pilotspaceeu

The best measured glide ratio of a Ventus at 15 metres wingspan is 44:1, improving to 46:1 with the 16.6 metre tips, giving a creditable performance for the 1980s and 1990s. Ventus sailplanes won two World Gliding Championships, competing against the ASW 20 and later the LS6 in the 15m class. Whilst the Ventus A and B acquired reputations for unparalleled high-speed glide performance, the Ventus C introduced improvements in handling.

About 613 Ventus sailplanes were built before being replaced by the Schempp-Hirth Ventus 2 in 1995.

Schempp-Hirth Ventus SchemppHirth Ventus 2cxT Untitled Aviation Photo 1111442

The Ventus 1 remains a competitive glider winning national level competitions. The ventus 1a is still being flown at the World Championship level in 2017.

Variants

data from:Schempp-Hirth Flugzeugbau GmbH website

Schempp-Hirth Ventus saleplane SchemppHirth Ventus 2 pilots aviation flying
Ventus A (15m / 16.6m)
The production standard 15m class Ventus with shorter and narrower cockpit.
Ventus B (15m / 16.6m)
Production aircraft with larger cockpit for larger pilot.
Ventus BT (15m / 16.6m)
The Ventus B with a retractable sustainer motor.
Ventus C (15m / 17.6m)
Later model with improved handling and air brakes separate from the trailing-edge flaps.
Ventus CT (15m / 17.6m)
The Ventus C with a retractable sustainer motor.
Ventus CM (15m / 17.6m)
The Ventus C with a retractable motor for self-launching.

Specifications (Ventus c)

Data from Jane's All the World's Aircraft 1988-89

General characteristics

  • Crew: 1
  • Length: 6.58 m (21 ft 7 in)
  • Wingspan: 17.6 m (57 ft 9 in) with extensions
  • Height: 1.27 m (4 ft 2 in)
  • Wing area: 9.96 m2 (107.2 sq ft) with extensions
  • Aspect ratio: 27.7 with extensions
  • Airfoil: Wortmann/Holigaus/Althaus section
  • Empty weight: 243 kg (536 lb)
  • Max takeoff weight: 430 kg (948 lb)
  • Water ballast: 160 l (42 US gal; 35 imp gal)
  • Performance

  • Stall speed: 64 km/h (40 mph; 35 kn)
  • Never exceed speed: 270 km/h (168 mph; 146 kn) in smooth air
  • g limits: +5.3 -2.65
  • Maximum glide ratio: 46.5 at 95 km/h (51 kn; 59 mph)
  • Rate of sink: 0.59 m/s (116 ft/min) at 75 km/h (40 kn; 47 mph)
  • Wing loading: 43.2 kg/m2 (8.8 lb/sq ft)
