Scheibe Tandem Falke

Updated on
Edit
Like
Comment
Share on FacebookTweet on TwitterShare on LinkedInShare on Reddit
Top speed

180 km/h

Length

8.1 m

Designer

Egon Scheibe

Wingspan

16 m

Manufacturer

Scheibe Flugzeugbau

Scheibe Tandem-Falke OE9299

The Scheibe SF 28 Tandem-Falke (German: "hawk") is a German motorglider that was designed by Egon Scheibe in 1970 and which flew for the first time in May the following year. It was a development of the Scheibe Falke with (as its name suggests) seating in tandem rather than side-by-side as in the original Falke design.

Contents

Scheibe Tandem-Falke SF 28 TandemFalke

Development

Scheibe Tandem-Falke Scale Soaring UK Scheibe SF28 Tandem Falke

The SF 28 is a low-wing, cantilever monoplane of conventional design with a large perspex canopy. The undercarriage consists of a non-retractable monowheel and a steerable tailwheel, linked to the rudder. Small outrigger wheels are fitted to nylon legs under each wing. The fuselage is of steel tube construction, covered in fabric and the wings are constructed of wood and fabric around a single spar.

Operational history

Scheibe Tandem-Falke WildbergAIR

Scheibe entered at least one Tandem-Falke in the German Motor Glider Competition of 1977. At least one SF28 was used by the Spanish military as 'UE 16-1' and demobilized in April 2008.

Specifications (SF 28A)

Data from Jane's all the world's aircraft, 1985-86

General characteristics

Scheibe Tandem-Falke AviationCornernet Aircraft photography Scheibe SF28A TandemFalke

  • Crew: 1
  • Capacity: 1
  • Length: 8.1 m (26 ft 7 in)
  • Wingspan: 16.3 m (53 ft 6 in)
  • Height: 1.55 m (5 ft 1 in)
  • Wing area: 18.5 m2 (199 sq ft)
  • Aspect ratio: 14.5
  • Airfoil: Göttingen 533
  • Empty weight: 410 kg (904 lb)
  • Max takeoff weight: 610 kg (1,345 lb)
  • Powerplant: 1 × Limbach SL 1700 4-cyl. air-cooled horizontally-opposed piston engine, 49 kW (66 hp)

    • Performance

    Scheibe Tandem-Falke Scheibe SF28A TandemFalke Untitled Aviation Photo 1284870

  • Maximum speed: 180 km/h (112 mph; 97 kn)
  • Range: 520 km (323 mi; 281 nmi)
  • Service ceiling: 5,000 m (16,000 ft)
  • Maximum glide ratio: 26:1 at 85 km/h (46 kn; 53 mph)
  • Rate of sink: 0.9 m/s (180 ft/min) at 69 km/h (37 kn; 43 mph)
  • Wing loading: 32.99 kg/m2 (6.76 lb/sq ft)

    • Scheibe Tandem-Falke cdnairplanepicturesnetimagesuploadedimages2
