Formula C6H2KN3O7,C6H2(NO2)3OK Density 1.85 g/cm³ | Molar mass 267.2 g/mol Melting point 250 °C | |
 | ||
Potassium picrate
Potassium picrate, or potassium 2,4,6-trinitrophenolate, is an organic chemical, a picrate of potassium. It is a reddish yellow or green crystalline material. It is a primary explosive. Anhydrous potassium picrate forms orthorhombic crystals.
Contents
History
Potassium picrate was first prepared as impure in mid-17th century by Johann Rudolf Glauber by dissolving wood in nitric acid and neutralizing with potassium carbonate. It is commonly made by neutralizing picric acid by potassium carbonate. It was used since 1869. Its chief applications are in pyrotechnics, in some whistle mixes, as a component of explosives (with potassium nitrate and charcoal), propellants (with potassium chlorate), and explosive primers (with lead picrate and potassium chlorate).
Description
Potassium picrate is not a very powerful explosive. It is somewhat shock-sensitive. In contact with flame it deflagrates with a loud sound. If ignited in confined space, it will detonate. It is more sensitive than picric acid.
In contact with metals (e.g. lead, calcium, iron), potassium picrate, like ammonium picrate and picric acid, forms picrates of said metals. These are often more dangerous and more sensitive explosives. Contact with such materials therefore should be prevented.
Potassium picrate is used to determine the concentration of nonionic surfactants in water; materials detectable by this method are called potassium picrate active substances (PPAS).
Synthesis
As with other picrates, potassium picrate may be produced by the neutralization of picric acid with the corresponding carbonate. As picric acid is barely soluble in water the reaction must be done in an appropriate solvent like methanol. First dissolving the picric acid in methanol and then adding potassium carbonate will result in potassium picrate. Temperature control is important to prevent detonation or excessive methanol evaporation.
Sensitivity
According to Urbanski, Potassium picrate detonated 10% of the time when struck by a mass of 2kg dropped from the height of 21cm. By comparison, the more sensitive anhydrous lead picrate detonated 10% of the time when struck by the same mass dropped from the height of 2cm.
