Pipistrel Taurus

Updated on
Edit
Like
Comment
Share on FacebookTweet on TwitterShare on LinkedInShare on Reddit
Top speed

130 km/h

Length

7.27 m

Manufacturer

Wingspan

15 m

First flight

2002

Pipistrel Taurus wwwpipistrelusacommodelstaurus5jpg

Pipistrel taurus autumn sightseeing flight in hungary


The Pipistrel Taurus is a Slovenian self-launched two-seat microlight glider designed and built by Pipistrel.

Contents

Pipistrel taurus motorized sailplane review by dan johnson


Development

Pipistrel Taurus Pipistrel Aircraft Taurus Pipistrel

Developed by Pipistrel as one of the first self-launched glider in the microlight category the design used the wings of the Pipistrel Sinus with a new two-seat side-by-side fuselage. To enable the Taurus to self-launch a pop-out propeller is mounted on the rear fuselage driven by a Rotax 503 piston engine. In 2007 the company developed the Taurus Electro with the piston engine replaced by a permanent magnet synchronous three-phase brushless motor.

Variants

Pipistrel Taurus Pipistrel Taurus Wikipedia
Taurus 503
Variant powered by Rotax 503 pop-up piston-engine.
Taurus Electro
Variant with a Sinedon 40 hp (30 kW) electric motor replacing the piston engine; first flown in 2007. It was the first electric motor glider to achieve series production.
Taurus PUREGLIDER
Unpowered variant without engine fitted.
Taurus Electro G2
Introduced in February 2011 as a two-seat self-launching sailplane, powered by a 40 kW (54 hp) engine and lithium batteries. Powered endurance is 17 minutes, intending to allow for self-launching to an altitude of 2000 m (6500 ft), after which the engine is retracted and the aircraft then soars as a sailplane.
Pipistrel Taurus Pipistrel USA Sinus Virus Taurus Apis LSA Aircraft Motorgliders
Taurus G4
One-off twin fuselage, four seat version, based on the Taurus Electro and acting as an engine development test bed for their forthcoming Panthera four seat hybrid. It has a 150 kW (201 hp) motor mounted on the central wing section between the fuselages. With two people on board, it was the winner of the Green Flight Challenge held in September 2011, covering 403.5 passenger miles per gallon gasoline equivalent and receiving the $1.35 million prize donated by NASA.

Specifications

Data from

General characteristics

Pipistrel Taurus Taurus Electro Pipistrel South Africa

  • Crew: 2
  • Length: 7.27 m (23 ft 10 in)
  • Wingspan: 14.97 m (49 ft 1 in)
  • Height: 1.41 m (4 ft 8 in)
  • Wing area: 12.33 m2 (132.7 sq ft)
  • Aspect ratio: 18.6
  • Empty weight: 285 kg (628 lb)
  • Max takeoff weight: 450 kg (992 lb)
  • Powerplant: 1 × Rotax 503 piston engine, 40 kW (54 hp)
  • Propellers: 2-bladed, 1.6 m (5 ft 3 in) diameter
  • Performance

    Pipistrel Taurus Pipistrel Aircraft Taurus Pipistrel

  • Maximum speed: 130 km/h (81 mph; 70 kn) with flaps extended
  • Stall speed: 63 km/h (39 mph; 34 kn) with flaps
  • Never exceed speed: 225 km/h (140 mph; 121 kn)
  • Maximum glide ratio: 41:1
  • Rate of sink: 0.7 m/s (140 ft/min)

  • Pipistrel Taurus Pipistrel Taurus Self Launch Glider A closer look YouTube
