Top speed

220 km/h

Length

5.5 m

Wingspan

8 m

First flight

March 15, 1953

PIK-11 httpsuploadwikimediaorgwikipediacommonsthu

Manufacturer

Polyteknikkojen Ilmailukerho

Pik 11 tumppu


The PIK-11 Tumppu ("Mitten") was a single-seat, single-engine sport aircraft developed in Finland in the 1950s. It was a low-wing, cantilever monoplane of conventional design with an enclosed cockpit and fixed, tailwheel undercarriage. It was to be the first powered aircraft produced by Polyteknikkojen Ilmailukerho, with the objective being building an aircraft for club use that was cheap to build and easy to fly.

Contents

Design work was started in 1948 by Kai Mellen and Ilkka Lounanmaa under the direction of Professor Arvo Ylinen. The first of four machines made its first flight on 15 March 1953. The prototype is preserved at the Finnish Aviation Museum, and another example was still listed on the Finnish Civil Aviation Authority registry in 2008.

In the early 21st century, a flying replica was under construction, to be powered by a Rotax 912 engine.

Specifications

Data from Jane's all the World's Aircraft 1955-56 &

General characteristics

  • Crew: 1
  • Length: 5.5 m (18 ft 1 in)
  • Wingspan: 8 m (26 ft 3 in)
  • Height: 1.65 m (5 ft 5 in) tail down
  • Empty weight: 238 kg (525 lb)
  • Gross weight: 373 kg (822 lb)
  • Powerplant: 1 × Continental A65-8 4-cyl. horizontally-opposed air-cooled piston engine, 48 kW (65 hp)

    • Performance

  • Maximum speed: 220 km/h (137 mph; 119 kn) at sea level
  • Cruise speed: 170 km/h (106 mph; 92 kn) at sea level
  • Landing speed: 80 km/h (50 mph; 43 kn)
  • Never exceed speed: 280 km/h (174 mph; 151 kn)
  • Range: 700 km (435 mi; 378 nmi)
  • g limits: +5.5 -1.5
  • Rate of climb: 5.5 m/s (1,080 ft/min) initial
  • Time to altitude: 1,000 m (3,300 ft) in 3 minutes 10 seconds, 5,000 m (16,000 ft) in 31 minutes
  • Wing loading: 41 kg/m2 (8.4 lb/sq ft)
  • Power/mass: 0.13 kW/kg (0.0787 hp/lb)
    Take-off run: 300 m (980 ft) to clear 15 m (50 ft)
