The Novi Avion (Serbian Cyrillic:Нови Aвион English: New Aeroplane) was a 4th-generation, supersonic multi-role combat aircraft project of cropped delta-canard configuration. The work was undertaken by the Vazduhoplovno Tehnicki Institut (VTI) (Aeronautical Technical Institute) of Belgrade, the former Yugoslavia's main military-technical institute, but cancelled just before production began in 1991.
Contents
- Tajni projekat novi avion
- Air serbia dobila novi avion airbus a330
- Overview
- Design
- Specifications
- References
Air serbia dobila novi avion airbus a330
Overview
The project was started in the mid-1980s in order to make Yugoslavia fully self-sufficient in the manufacture of military equipment, and air superiority fighter jets were the only thing that Yugoslavia still had to import, having obtained the capability to build all other military equipment by the 1980s. When Yugoslavia disintegrated in 1991, the project was cancelled, since the break-up of the country made the financial resources necessary to start production of the plane unavailable.
The design was approximately one year from completion at the time of cancellation, and design of some production facilities and prototypes of some parts such as the cockpit had already been built. Had it not been cancelled, it would have had its first flight in 1992, and entered service some time in the mid 1990s.
Yugoslavia expected to build approximately 150 of these planes to replace its MiG-21s and J-21 Jastrebs, and a sale of several hundred Novi Avions on the world market was also anticipated. The term Novi Avion was used to describe the project and the aircraft would have received a proper designation upon entering service.
Design
The Novi Avion most closely resembled the French Rafale, although it was smaller and had only one engine. It was designed to fill many roles, including air superiority, interception, reconnaissance, ground attack, and anti-ship attack. Maximum speed was just under Mach 2. Super-maneuverability at both supersonic and subsonic speeds was a priority, and a major portion of the airframe was to be composed of composites.
The design was to incorporate a number of features to lower its radar cross-section, although it would not have been a true stealth aircraft. The aircraft was to carry an advanced ECM/ECCM suite. It was an all-Yugoslav design, not based on any foreign plane, although France was providing some assistance with the design of the most complex parts that Yugoslavia had no experience with, such as a multipurpose radar.
The engine was to be the French Snecma M88, the same engine used in the Rafale. Most of the weapons it would have carried would probably have been either French weapons, or built with French assistance.
Specifications
General characteristics
Performance
Armament
Avionics
