Lublin R XII

Design and development

Plage i Laśkiewicz works was among factories, that developed sports aircraft for an order of the LOPP paramilitary organization. Its design, the Lublin R-XII, was basically a scaled down passenger plane Lublin R-XI. The main designer was Jerzy Rudlicki. The only prototype was flown in autumn 1930 (registration SP-AFB). It was not built in series.

The plane was not successful and its performance was not satisfactory because of too much weight. It did not take part in the 3rd Polish Light Aircraft contest because of a weight limit. It was owned by the factory and little used, after a few years it was scrapped. The R-XII was the only sports plane of Plage i Laśkiewicz.

Description

A mixed construction cantilever high-wing monoplane, single-engine, conventional in layout. It had a steel framed, canvas covered fuselage (engine part covered with duralumin) and a single-piece, plywood-covered, two-spar elliptical wing of wooden construction. The empennage was of steel construction, canvas covered. In a closed cabin under the wing there were two places side-by-side, with double controls, behind them was the third seat or a place for baggage. The cabin had single door on the left and front and rear doors on the right. It had a conventional fixed landing gear, with a rear skid, the main gear was joined with wings by vertical struts with oil and air shock absorbers. It had a single 5-cylinder air-cooled Armstrong-Siddeley Genet uncovered radial engine in front, delivering 88 hp take-off power and 80 hp nominal power, driving a two-blade propeller. A fuel tank was in the fuselage. The cruise fuel consumption was 21 l/h.

Specifications

Data from Glass, A. (1977)

General characteristics

Performance
