Cruise speed 362 km/h Length 7.77 m Wingspan 11 m Unit cost 350,000–550,000 USD | Weight 907.2 kg Range 2,173 km | |
 | ||
Lancair es build p2
The Lancair ES is an American amateur-built aircraft that was designed and produced by Lancair. While it was in production the aircraft was supplied in the form of a kit for amateur construction.
Contents
- Lancair es build p2
- Great planes lancair es 60
- Design and development
- Operational history
- Specifications Super ES
- References
Production of the aircraft kit was ended in 2012.
Great planes lancair es 60
Design and development
The aircraft features a cantilever low wing, a four-seat enclosed cabin that is 46 in (117 cm) wide, fixed tricycle landing gear and a single engine in tractor configuration.
The aircraft is made from composites. Its 35.5 ft (10.8 m) span wing employs a McWilliams RXM5-217 airfoil at the wing root, transitioning to a NACA 64-212 at the wingtip. The wing has an area of 140 sq ft (13 m2) and mounts flaps. The aircraft's recommended engine power range is 210 to 310 hp (157 to 231 kW) and standard engines used include the 310 hp (231 kW) Continental IO-550 (Super ES) four-stroke powerplant. Construction time from the supplied kit is estimated to be 2000 hours.
In July 2016 the company announced it would be selling the older Lancair lines of aircraft to concentrate on the Lancair Evolution instead. Once the transition is complete the company will change its name to the Evolution Aircraft Company.
Operational history
By December 2011, 90 examples had been completed and flown. At least two examples have utilized custom engine mounts to allow installation of Lycoming IO-540 engines.
Specifications (Super ES)
Data from Kitplanes
General characteristics
Performance
