Length

8 m

Manufacturer

Ilyushin

Wingspan

11 m

Designer

Genrikh Novozhilov

Ilyushin Il-103 barrieaircraftcomimagesilyushinil10302jpg

Ilyushin il 103 commercial cargo prop plane features photos


The Ilyushin Il-103 is a single-engine, low-wing training aircraft developed by the Ilyushin Design Bureau starting in 1990 in the Soviet Union. The aircraft is now produced in Russia. It was the first Russian aircraft to achieve Federal Aviation Administration certification for sales in the United States.

Contents

Ilyushin Il-103 Ilyushin Il103 Untitled Aviation Photo 1970860 Airlinersnet

Produced by RSK-MiG, it has been adopted by the Republic of Korea Air Force as a primary trainer, where it is known as the T-103.

Ilyushin Il-103 Iljuschin Ilyushin Il103 Specifications Technical Data

Ilyushin il 103 commercial cargo prop plane photos specs


Users

The following is a list of import versions of the II-103:

 Laos
  • Lao People's Liberation Army Air Force: three delivered with 21 ordered
    •  South Korea
  • Republic of Korea Air Force: 22 (23 delivered/ one lost to crash, 2011.)
    •  Peru
    Ilyushin Il-103 Ilyushin T103 Il103 South Korea Air Force Aviation Photo

  • Peruvian Army: six delivered / one crash w/fire damaged beyond repair. No-injuries (Officers at Ejercito Del Peru - Peruvian Army)

    • Specifications (Il-103)

    Ilyushin Il-103 Ilyushin Il103 Photo and video Characteristics History

    Data from Type Certificate no A45SE FAA received in December 1998, Type certificate No. 89-103 THE AR IAC received in February 1996. Type certificate No. A45SE FAA received in December 1998

    General characteristics

    Ilyushin Il-103 Ilyushin T103 Il103 South Korea Air Force Aviation Photo

  • Crew: two, stick controls
  • Capacity: three places in back, total seating=five
  • Length: 8 m (26 ft 3 in)
  • Wingspan: 10.56 m (34 ft 7.75 in)
  • Height: 3.135 m (10 ft 3.5 in)
  • Wing area: 14.71 m2 (158.34 ft2)
  • Empty weight: 900 kg (1984 lb)
  • Gross weight: 1310 kg (2888 lb)
  • Powerplant: 1 × Continental IO-360ES- Fuel Injected - piston engine with one Hartzell BHC-C2YF-1BF/F8459A-8R two-blade variable pitch (hydraulic) metal propeller, 156 kW (210 hp)

    • Performance

    Ilyushin Il-103 Ilyushin Il103 Wikipedia

  • Range: (at cruising speed, pilot and 270 kg (595 lb) payload and 30 min reserves): 800 km (497 miles)
  • Service ceiling: (max certified altitude): 3000 m (9840 ft)
  • Rate of climb: (at ISA mean sea level): 3.167 m/s ( ft/min)

    • References

    Ilyushin Il-103 Wikipedia
