Range

6,300 km

Cruise speed

850 km/h

Engine type

Turbofan

Top speed

900 km/h

Introduced

1999

Manufacturer

Gulfstream G200 wwwgulfstreamcomimagesmadeimagesuploadspreo

Gulfstream g200 sn 16 aircraft for sale


The Gulfstream G200, formerly known as the IAI Galaxy is a twin-engine business jet. It was designed originally by Israel Aircraft Industries (IAI) and was produced for Gulfstream Aerospace from 1999 through 2011.

Contents

Gulfstream G200 Private Jet Charter Hire Gulfstream G200 PrivateFly

Gulfstream g200


Design and development

Gulfstream G200 Gulfstream G200 specifications Planescom

The G200 was originally named "Astra Galaxy". Israel Aircraft Industries' subsidiary Galaxy Aerospace Inc began designing the Galaxy in the late 1980s in a risk-sharing partnership with the Soviet aircraft design bureau Yakovlev OKB. The program officially launched in September 1993. Yakovlev handled design and manufacturing of the forward fuselage and empennage. However, the Russian company had trouble meeting agreed production schedules, and the partnership was ended in 1995. This led to another risk-sharing agreement, with EADS Sogerma manufacturing the fuselage and empennage, and IAI being responsible for final assembly and other prime contractor duties.

Gulfstream G200 Avjet Announces One Way Charter Pricing with Gulfstream G200

The Galaxy was based on a new wider fuselage, attached to a strengthened Astra SPX wing with integrated winglets and modified high lift devices, powered by new 5,700 lb (25.3 kN) thrust Pratt & Whitney Canada PW306 turbofans, and with improved Pro Line 4 avionics and all-new interior. The decision to use the existing Astra SPX wing imposed a limit on maximum size, but allowed for a fuselage large enough to accommodate three-abreast seating. The main change from the Astra SPX wing was the introduction of Krueger flaps on the leading edges of the inboard section. These recovered some of the field performance lost as a result of the Galaxy's higher wing loading. It used rubber de-ice boots on wing and horizontal stabilizer leading edges. The aircraft has seating configurations for 8 to 10 passengers. The G200 has a forward tilting stance when on the ground.

Gulfstream G200 Gulfstream G200 Wikipedia

The Galaxy first flew on December 25, 1997. By December 1998 it had received certification from the US and Israeli aviation agencies. Deliveries began the following year. The Galaxy was renamed "G200" after Gulfstream Aerospace acquired Galaxy Aerospace in June 2001.

Gulfstream G200 Private Air Charter Gulfstream G200 with Execflyer

In 2005, Gulfstream began designing a follow-on aircraft. The new model, known as the G250 was launched in 2008. It was later renamed the Gulfstream G280. The final production G200 rolled off the production line on December 19, 2011; 250 units had been built.

Specifications

Data from Frawley Gulfstream G200 data

General characteristics

Gulfstream G200 Gulfstream G200 Private Jet Charter Stratos Jet Charters

  • Crew: 2
  • Capacity: Typical Seating of 8-10, 18 Max
  • Payload: 4,050 lb (1,840 kg)
  • Length: 62 ft 3 in (18.97 m)
  • Wingspan: 58 ft 1 in (17.70 m)
  • Height: 21 ft 5 in (6.53 m)
  • Wing area: 369 ft² (34.3 m²)
  • Empty weight: 19,200 lb (8,709 kg)
  • Max. takeoff weight: 35,450 lb (16,080 kg)
  • Powerplant: 2 × Pratt & Whitney Canada PW306A turbofans, 6,040 lbf (26.9 kN) each
  • Performance

  • Maximum speed: Mach 0.85 (487 knots, 560 mph, 900 km/h) at altitude
  • Cruise speed: Mach 0.80 (459 knots, 528 mph, 850 km/h) normal cruise at altitude
  • Range: 3,400 nmi (3,910 mi, 6,300 km) at Mach 0.75 with 4 passengers
  • Service ceiling: 45,000 ft (13,700 m)
  • References
