Founded  1979
Parent organization  Trilogy Systems

Tata elxsi corporate video

Elxsi (now Tata Elxsi) was a minicomputer manufacturing company established in the late 1970s along with a host of other competitors (Trilogy Systems, Sequent, Convex Computer) in Silicon Valley, USA. The Elxsi processor was an Emitter Coupled Logic (ECL) design that featured a 50 nanosecond clock, a 25 nanosecond backpanel bus, IEEE floating point arithmetic and a 64-bit architecture. It allowed multiple processors to communicate over a common bus called the Gigabus, believed to be the first company to do so. The operating system was a message based operating system called EMBOS. The Elxsi CPU was a microcoded design, allowing custom instructions to be coded into microcode.



Elxsi was founded in 1979 by Joe Rizzi (previously a manager at Intersil) and Thampy Thomas (who would go on to found NexGen Microsystems). It is believed that Elxsi was the first startup founded by an Indian in Silicon Valley. Much of the architecture of the Elxsi machine was designed by former Stanford University professors Len Shar and Balasubrimanian Kumar. Another key contributor to the design was Harold (Mac) McFarland, who was also a key designer on the team that created the PDP-11. George Taylor (on the IEEE standard committee and a student of UC Berkeley Professor William Kahan) provided a key design for the IEEE floating point unit. Elxsi was bought out by Gene Amdahl with money that was left over from the Trilogy venture.

Venture investors in Elxsi included Tata Group (India) and Arthur Rock. In 1989, however, Elxsi left the computer business because of the general shift away from the use of mainframes in the global computer industry and the advent of the personal computer. The Tata Group kept the name Tata Elxsi but it now belongs to the Tata group of companies.

The original Elxsi Corporation, however, remained in business as a going concern. In 1989, the company sold its computer maintenance business to National Computer Systems. In 1991, the company entered two entirely different lines of business: restaurants and sewer inspection equipment. ELXSI is still engaged in these businesses, as well as its CUES unit, which makes video pipeline inspection equipment.

Before its withdrawal from the computer industry, the large range of hardware expansion gave the machine some success in departmental technical computing environments. The 64-bit registers and ability to do parallel adds within them gave it an unanticipated advantage in COBOL benchmarks, where it outperformed some mainframes. And the extreme independence of the CPUs (lack of cache snooping and invalidation), coupled with the ability to lock processes into register sets and later, the ability to partition the caches, gave it some success in real time applications.


The machine was a mini-supercomputer: a category of computers that was larger than a VAX 11/780 and smaller than a mainframe. This market segment disappeared as high end microprocessor based systems became more powerful.

The architecture was unusual, especially for its day. The system bus connected as many as 12 CPUs and I/O processors. Each CPU was built from 3 large boards of ECL gate arrays. Key elements of its instruction set architecture were:

  • 16 registers (64-bit)
  • 32-bit linear address space (64-bit integers but 32-bit pointers)
  • Multiple register sets per processor, with switches among processes loaded into register sets handled by microcode
  • Small set of basic addressing modes
  • Small set of instruction lengths, length determinable from first few nibbles of instruction
  • No hardware cache coherence among processors
  • Microcoded message system to communicate among software processes and with I/O controllers and CPU microcode
  • No supervisor mode—equivalent restrictions applied by controlling which processes held special message system communication links and which virtual address space had the memory management tables mapped into it
  • Multiple hardware CPU interrupts that supported real-time computing applications (e.g., flight simulators and industrial process controllers)
  • Two generations of CPU were sold and a third developed but never sold. All plugged into the same backplane and could be intermixed in a single system.
  • Software

    The EMBOS OS was written entirely from scratch in a slightly extended Pascal. It was a multi-server architecture (like GNU Hurd, but long predating that project). The UI was Unix-like, especially at the shell level, with similar concepts but different commands, syntax, etc. (e.g. "files" instead of "ls"; "find" instead of "grep"). Later, a Unix kernel was hosted on top of the lower-level servers so that EMBOS and Unix processes and users could co-exist (ENIX). VMS compatibility software running on top of EMBOS was also added to ease porting of VAX applications.

    Famous employees

    Although Elxsi was not a financial success, many of its employees did go on to fame and fortune.

  • Ralph Merkle (who wrote the Elxsi Fortran compiler) later became a noted nanotechnologist.
  • Rob Catlin became an early employee of Chips and Technologies.
  • Thampy Thomas became a founder of NexGen, which was later acquired by AMD. The NexGen design became the design for the AMD K6 processor.
  • Mac McFarland was also an early NexGen employee. Mac's role in the design of the PDP-11 is given in Gordon Bell's history of DEC (page 87) [1]
  • B. V. Jagadeesh became a founder of Exodus Communications took it public in 1998 and became CEO of NetScaler in Aug 2000 and successfully sold to Citrix for $325M in 2005
  • Bob Rau and Arun Kumar became founders of Cydrome. Bob then worked at HP Labs and was one of the developers of the IA-64 architecture. [2]
  • Allen Roberts and Harlan Lau became early employees of Rambus
  • John Sanguinetti founded Chronologic and wrote the VCS Verilog Compiler [3]
  • Robert Olson became the founder of Virtual Vineyards (now, and later served as an engineering executive with several Internet-focused startups, such as PostX (
  • Mike Farmwald (an Elxsi consultant) founded several Silicon Valley high tech companies.
  • Jim Kaschmitter is the CEO of UltraCell, a maker of micro fuel cells
  • Sha-shu Lin was a founder at iPlanet and is now VP of Eilink [4]
  • Kevin McGrath is an AMD Fellow and developed the 64 bit extensions for the AMD64 architecture.
  • Russell Williams is an architect and engineer of Adobe Systems Photoshop
  • Loren Kohnfelder originated the idea of the digital certificate and developed security for the Microsoft Internet Explorer.
  • Herbert (Bert) Slade, Vice President of Field Service
  • Stuart Sackman is Vice President, Global Product and Technology at ADP
