Dynaco

Early company history

In 1950 David Hafler and Herb Keroes started a Philadelphia-based company called Acrosound in order to build and sell audio-quality output transformers, primarily for home electronics hobbyists. The two men refined and developed the Ultralinear audio circuit pioneered by British audio electronics engineer Alan Blumlein, using taps from the output transformer to feed signal back into the output stage screen grid circuitry. The Acrosound transformer circuit was later used in many home-built and commercial hi-fi amplifiers in the early 1950s. In order to appeal to a wider consumer market, Hafler decided to design and build entire power amplifiers as build-it-yourself kits, complete with preassembled, tested circuit boards that only required the customer to wire the boards to the transformers, controls, and power supply to complete the project. This was a considerable advance over other audio system kits of the day, which generally required the purchaser to assemble and test the PC boards themselves, a relatively precise and time-consuming task.

In 1954 Dave Hafler and Herb Keroes parted company. During a visit to the New York-based Brociner Electronics the same year, Hafler met an audio engineer named Ed Laurent, who had designed a novel single-tube driver circuit for a power amplifier. In 1955, the two men founded the Dyna Company (later Dynaco) with the intention of not only producing transformers, but high-quality audio circuitry. The company was incorporated in October 1955, with business premises located at 617 N. 41st St in Philadelphia. Dynaco's first product was the Mk. II 50-watt power amplifier. Available as a kit or preassembled unit, the Mk. II was sold for several years until its replacement in 1956 by the Mk. III amplifier, which produced 60 watts. Hafler wrote an article for Radio-Electronics Magazine in 1955 delineating the design of a high-power version of the Williamson amplifier using Ultralinear circuitry and Dynaco's new output transformers. The Williamson amplifier utilized a slightly different circuit design from the Mk. II and Mk. III. Shortly thereafter, the company moved its business operations to 3912 Powelton Avenue in Philadelphia, where they remained for several years.

Products

Today, Dynaco is best remembered for its highly regarded vacuum tube stereo amplifier, the Stereo 70 (ST 70). Introduced in 1959, the ST 70 was available as a kit (Dynakit) intended for assembly by the purchaser or as a complete factory-wired unit. The ST 70 used four EL34 output tubes, one GZ34/5AR4 rectifier tube, two 7199 input (driver) tubes, two output transformers, one power transformer, and a preassembled printed circuit board (PCB) containing the driver circuit. It produced 35 watts per channel (wpc). The driver circuit had a single 7199 pentode/triode tube per channel, and used the driver tube to handle both voltage amplification and phase splitting. The output transformers are an ultralinear design, whereby part of the primary winding is fed back to the output tube's screen grid. This design reduced distortion and improved audio quality.

A masterpiece of efficient circuit design, the ST 70 provided reliable, high-quality audio amplification at an affordable price. The popularity of the ST 70 contributed more than any other single product to continuing consumer interest in tube-based stereo amplifiers at a time of increasing market dominance by solid state audio products. Because of its excellent value for cost, Dynaco tube amplifiers were often referred to as "the poor man's McIntosh." More than 350,000 ST-70 amplifiers had been sold when production finally ceased, making the ST 70 the most popular tube power amplifier ever made.

A smaller tube amplifier, the 17.5wpc Stereo 35, was introduced in 1963, and was followed the next year by the SCA 35, the company's first integrated (preamp + power amp) tube amplifier. In 1992, an updated version of the Stereo 70, the Stereo 70 II, was produced by Sound Valves for Panor Corporation. Even today, upgraded components, rebuilding kits, and complete tube amplifiers using the basic Stereo 70 design are still in production, and the ST 70 has inspired numerous other amplifier designs, such as Ars-Sonum's Filarmonia SE. Dynaco continued to build both mono and stereo amplifiers until 1977. The company's final contribution to vacuum tube technology was the massive Mk. VI mono power amplifier of 1976, which produced 120 watts (continuous).

In later years, the company began to produce a line of solid-state audio components, commencing in 1966 with the introduction of the Stereo 120 power amplifier (60 wpc). Because of early problems involving circuit, power supply, and transistor failures, the ST 120 was not as popular as earlier Dynaco tube amplifiers. Numerous small circuit changes were introduced by Dynaco over the years in an attempt to improve the stability and reliability of the ST 120, without much success. With the PAT-4 preamplifier in 1967, the company affirmed its ability to design reliable solid state equipment at an affordable price. In the 1970s, the Stereo 400 was developed and marketed. This was a high power amplifier at 200 watts per channel that offered automatic protection circuitry to prevent electrical destruction of the loudspeaker. The FM-5 tuner was offered as was the SCA-80 integrated amplifier in the early 1970s time line. There was also the Dynaquad system which allowed the user to simulate a quadrophonic sound by using out of phase signals at the speaker terminals. It apparently was a success and offered good four-channel sound at budget price. Dynaco's solid-state kits were different from the popular Heathkit products (and Dynaco's own vacuum tube kits) because of their preassembled circuit boards. These boards were wired at the factory, tested and packaged with the unassembled chassis. It remained only for the consumer to attach the switches and controls to the chassis pieces, assemble the chassis and power supply, and solder connecting wires to the circuit boards. This saved considerable time and reduced error in assembly.

Dynaco also distributed the famous SEAS 'A-Series' of bookshelf loudspeakers that were manufactured in Denmark, using input from Dynaco's David Hafler and SEAS' Ragnar Lian. The A-Series were marketed between from 1970 until Dynaco's demise in the 1980s. The Dynaco A-25 model proved to be extremely successful, selling between 600,000 and 1,000,000 units. A modified aperiodic bass reflex design using SEAS speakers in a handsome wood cabinet, the A-25 sold for $79.95 each in 1969 making it competitive with much more expensive loudspeakers. The patented aperiodic (essentially non-resonant) woofer design utilized a highly damped vent instead of a reflex port, whose acoustic resistance is very carefully controlled. The resistant venting action lowered the "Q" of the system and reduced impedance variation near resonance in the A-Series speakers. Dynaco followed the A-25 with the slightly larger A-35, which featured a dual-chambered, non-vented design in a walnut-veneered cabinet with even greater transparency and fidelity. Over time, Dynaco marketed a wide range of loudspeakers, ranging from the small A-10 model to the floor standing A-50 series. After some 30 years, these loudspeakers still command good prices in markets such as eBay, and are a testimonial to their quality.

Concurrent with A-25 production, Dynaco introduced a speaker system whereby 4-channel sound could be easily derived from stereo material by using a rear channel speaker matrix. This "Dynaco patent" required a single resistor and a threeway potentiometer for the two rear speakers for generating sufficient phase difference signals for a feeling of ambience. The system worked best when the stereo sound had been recorded via two bidirectional microphones on the same spot. When microphone set-up changed to the use of multiple directional microphones and multitrack tape recording and postprocessing (i.c. in the CD era), the Dynaco patent lost its market value.

Dynaco became a wholly owned subsidiary of Tyco, Inc. in 1969. David Hafler remained with the company a few years longer, but left in 1974 to join Ortofon, manufacturer and importer of high-end phono cartridges. In 1977, Hafler founded the Hafler Company, continuing the tradition of high quality but inexpensive kits and assembled hi-fi gear.

In the late 1970s, Dynaco released a short-lived set of new loudspeakers developed by Ed Laurent, the Phase III. The speakers were well regarded by the audiophile community, but their introduction was apparently too late to make any strong impression in the marketplace, and Ed Laurent left shortly afterward to join SEAS Corporation. After Dynaco closed its USA operations, its former Canadian subsidiary released the Dynaco A-150, A-250, and A-350 speakers, all manufactured in Canton, Massachusetts. Critical reviews of the new audio speakers were not favorable, and they disappeared from the market in the mid-1980s.

In 1991 the Pan Orient Corporation (later Panor Corporation) acquired the Dynaco trademark, and in 1993 began marketing electronic audio components with the Dynaco brand. Panor introduced some new products and reintroduced the Stereo 70 as the Stereo 70 II. Panor/Dynaco's most ambitious stereo tube amplifier was the Stereo 160, a 75wpc, all-tube stereo power amplifier with switchable pentode/triode modes, adjustable tube bias potentiometers, and 6550 output tubes. While Panor owns the Dynaco brand name and trademark, there is no longer any direct connection with the company founded by David Hafler.

Dynaco Tube Equipment

Dynaco introduced the following tube audio amplifiers, tuners, and preamplifiers between 1955 and 1976.
