Cozy MK IV

Design and development

The aircraft is constructed primarily of fiberglass, foam, and epoxy. Urethane foam is used to form highly curved, hand-carved shapes such as the nose and wing tips. Blue rigid styrofoam is cut with a hot wire saw to form the wing cores. Thin PVC foam sheets are used to form bulkheads and the fuselage sides. Two types of woven fiberglass are used to provide the surface strength of the composite sandwich. RA7715 fiberglass is almost entirely unidirectional in its fiber orientation. RA7725 has an equal portion of perpendicular fiberglass strands. Epoxy systems used include EZ-Poxy, Safe-T-Poxy, MGS L285 and L335, and West Systems. The builder does not need pre-fabricated items to finish the aircraft except for the landing gear bow and nose gear strut which require forms and an oven for post curing, but several suppliers exist for these parts.

The recommended engine is the 180 hp (134 kW) Lycoming O-360, but a variety of powerplants from 160 to 220 hp (119 to 164 kW) have been used. One installation uses two Suzuki 1600 automobile engines driving two concentric contrarotating propellers.

Previous Versions and Related Aircraft

Cozy

Like the Long-EZ, the design includes a retractable nose gear and fixed main gear. With both front seats unoccupied, the center of gravity with the aircraft level is aft of the main gear. Thus, like the Long-EZ, the Cozy is parked with the nose resting on the ground, sometimes called "grazing". The nose-down position is very stable. The aircraft can withstand high winds as the wings are beyond a flying angle of attack. Some Cozy builders modify the design to include retractable main gear. This modification increases the maximum speed by a few knots. Maximum fuel tank capacity is reduced to accommodate the retracted gear.

Cozy III

The Cozy III was a 3-seat aircraft and the predecessor of the 4-seat Cozy Mark IV. Also designed by Nat Puffer, the Cozy III was initially referred to as simply "The Cozy". When the 4-place was announced, the qualification of the Cozy III name was required.

Cosy Classic

The Cosy Classic is the European version of Cozy III, changed to a forward opening canopy and other modifications. The forward opening canopy design is available from Uli Wolter, the designer of the Cosy Classic modifications.

Specifications (Cozy MK IV)

Data from

General characteristics

Crew: one

Capacity: four passengers

Length: 16 ft 10.8 in (5.151 m)

Wingspan: 28 ft 1.2 in (8.565 m)

Height: 7 ft 10.8 in (2.408 m)

Wing area: 88.3 sq ft (8.20 m²)

Empty weight: 1,050 lb (476 kg)

Gross weight: 2,050 lb (930 kg)

Powerplant: 1 × Lycoming O-360 four-cylinder, direct-drive, horizontally opposed, air-cooled, piston aircraft engines, 180 hp (130 kW)

Performance

Cruise speed: 191 kn; 354 km/h (220 mph) @ 75% power

Range: 1,300 nmi (1,496 mi; 2,408 km) At 50% power

Service ceiling: 20,000 ft (6,100 m)

Rate of climb: 1,200 ft/min (6.1 m/s) gross
