Cox box

Use

Mainly used in Eights and Fours the read outs are used by the coxswain to monitor the performance of the crew and manage the race. This is of particular importance in Head of the River (time trial) races where the crews race line astern and so performance of other crews cannot be easily gauged. It is also critical to assisting the coxswain in sticking to the race plan, which usually involves strategic changes of rating.

The amplifier is linked to one or more loudspeakers along the boat making it easier for the crew to hear commands, this is particularly important for the rower in the bow seat as they are often furthest away. The coxswain typically wears a headband-mounted microphone, which is attached by a wire and quick release to the amplifier. Some units allow a walkie-talkie connection to the coach so they can use the amplification to speak directly to the crew as well.

Rowing shells fitted with speed measuring impellers or GPS can report boat speed to the amplifier display, typically measured in Meters/second or 500 meters predicted split time. GPS speed measurement is presently only on Coxmate SCT and SX units.

History

Before the development of the Cox Box by Nielsen-Kellerman, a megaphone strapped to the head of the coxswain was used to make the coxswain easier to hear, and the coxswain used an analog stop watch and rate watch - quite a handful when also trying to steer a 60' long racing shell! The use of a system with multiple speakers also became much more important when racing eight construction switched to sealed bulkhead sections to ensure the boat would remain safely buoyant even when damaged. This is because sound could no longer travel down the hull as was possible with the previous open style of construction.

Strokes per minute (SPM) or rating

Almost all modern coxswain's amplifier systems have a liquid crystal display, showing the strokes per minute (SPM). On most systems, a magnet is positioned under the stroke man's seat. In bowloaded boats, the magnet is placed under the bow man's seat. As the rower moves up the slide (moving forward to prepare for the next stroke), a measurement is taken, and fed to the system. The stroke seat (first rower in the stern) sets the rate of rowing for the whole crew so this is very important. The display also usually features a timer which can be stopped, cleared, and reset, along with a stroke counter. For rows in poor lighting, the display is also equipped with a backlight.

Relevance of stroke rating

The stroke rating is extremely important when competing race events, either longer head races or short sprints. A high stroke rating would mean that the strokes of the rowers could potentially be less than perfect as they may be hurried and this could unbalance the boat. If the balance of the boat is not good, then the rowers will not be able to cover the blade properly, meaning that a smaller amount of water would be displaced, moving the boat a distance which would be less than that of a boat which is perfectly balanced. If the stroke rate is continuously too high, there is less of a chance of winning the race at all as distance is lost every stroke.

For example: If 400 strokes are taken in 3 kilometre head race, and due to poor technique the boat loses 1 m a stroke they will fall behind around 400 m compared to a perfectly rated opponent crew in the same time period, even though the rowers of both crews have put the same amount of effort into taking the strokes.

A high rating will also cause the crew to tire more quickly, as a result their technique may suffer. It is, however, generally accepted in the rowing community that the higher the level of fitness of the rowers, the higher the stroke rating can be without negatively affecting balance or technique.

Rowing is not just about the sheer power, but also about technique and precise timing, as well as holding to the race plan when things get tough. These are easier to manage using a coxswain's amplifier system such as a Cox Box.
