ARSAT 2

Updated on
Share on FacebookTweet on TwitterShare on LinkedIn
Operator  ARSAT
SATCAT no.  40941
Spacecraft  ARSAT-2
Rocket  Ariane 5
Mission type  Communications satellite
COSPAR ID  2015-054B
Mission duration  15 years
Launch date  30 September 2015
Bus  ARSAT-3K
ARSAT-2 Lanzaron el satlite argentino Arsat2 Arsat Satlite Infobae
Launch mass  2,977 kilograms (6,563 lb)
Manufacturers  INVAP, Thales Alenia Space
Similar  ARSAT‑1, ARSAT‑3, Sky Muster, Star One C4, Intelsat 21

Arsat 2


ARSAT-2 is a geostationary communications satellite operated by ARSAT and built by the Argentine company INVAP. It was launched from French Guiana alongside Sky Muster satellite using an Ariane 5ECA rocket on September 30, 2015 at 20:30hs UTC, becoming the 400th satellite to be launched by Arianespace. It is licensed to be located at 81° West longitude geostationary slot. ARSAT-2 is the second geostationary satellite built in Latin America, after ARSAT-1. Structurally and mechanically it is a copy of the ARSAT-1, the only difference being the payload and thus it has different antenna configuration.

Contents

ARSAT-2 Argentine satellite launch ready Arsat2 laInfoes

Va226 ariane v sky muster and arsat 2 launch replay


Payload

ARSAT-2 Haba arreglo Le dieron el Arsat 2 al grupo Clarn y a TyC

ARSAT-2 payload was supplied by Thales Alenia Space of France. It consists of both Ku band and C band sections.

ARSAT-2 Islas Malvinas 01 El satlite argentino ARSAT 2 se encuentra rumbo

The Ku band has 20 physical transponders. Of those, sixteen have a 36 MHz bandwidth and four have 72 MHz. Thus the satellite has a maximum capacity of 864 MHz Ku or 24 transponder equivalent. A 2 m (6.6 ft) deployable antenna and a 1.3 m (4.3 ft) fixed Gregorian antenna.

ARSAT-2 httpsuploadwikimediaorgwikipediaen117ARS

The C band section has a single 1.6 m (5.2 ft) deployable antenna that is fed by six physical transponders. Four have 72Mhz of bandwidth and the other two have 88 MHz. The total available C Band bandwidth is thus 464 MHz (or 12.9 transponder equivalent).
