AAUSAT II

Updated on
Share on FacebookTweet on TwitterShare on LinkedIn
Mission type  Technology
COSPAR ID  2008-021F
Mission duration  6 months planned
Operator  AAU StudentSpace
SATCAT №  32788
AAUSAT-II
Website  www.aausatii.aau.dk%20aausatii.aau.dk

AAUSAT-II is the second student-built CubeSat built and operated by students from Aalborg University in Denmark. It was launched 28 April 2008 05:54 UTC from Satish Dhawan Space Centre in India on a PSLV rocket. AAUSAT-II carries a radiation sensor.

Contents

The educational objective

The primary purpose of construction of satellites at Aalborg University is to give the students engineering capabilities beyond what is normally achieved within a masters program.

History

Student satellite activities at Aalborg University (AAU) started in 2003 as a result of AAU's involvement in the first pure Danish research satellite, Ørsted, which was successfully launched in 1999.

AAUSAT-II's predecessor was AAU CubeSat which was constructed in the period 2001-2003 and was launched 30 June 2003.

The construction of AAUSAT-II began in 2005.

Operations

After launch April 28, 2008 AAUSAT-II beacon was received at Cal Poly University in California but two-way amateur radio communications could not be achieved as it turned out that AAUSAT-II was transmitting at a lower level than anticipated. After upgrades to the ground station were completed, fully functional two-way communication were achieved and continued with normal operations until May 2009 after a year of successful operation.

The ground station has remained in operation and beacons are received on a regular basis and AAUSAT-II is still considered operational - although heavy tumbling is observed (December 2009)

Beacons are still received on regular basis in March 2011. In addition AAUSAT-II does receive and acknowledge commands from ground and log files has been requested and received. Due to the very high tumbling (more than 2.5 Hz) it has not been possible to decode log files.

Below is a snapshot of the radio communication. On left side is a beacon, next a request for log is issued and AAUSAT-II reply with a transmission of the logfile. Notice the high tumbling rate.

Mission definition

AAUSAT-II consists of several sub-systems:

  • ADCS: Attitude Determination and Control System
  • CDH: Command and Datahandling System
  • COM: Communication System
  • EPS: Electrical Power System
  • GND: Ground Station
  • MCC: Mission Control Center
  • MECH: Mechanical System
  • OBC: On-board Computer System
  • P/L: Payload System
  • Technical Facts:

    Amateur radio information

  • Callsign: OZ2CUB
  • Up/downlink: 437.425 MHz AFSK & FSK
  • Bit rate: 1200-9600 bit/s (1200 as standard mode)
  • AX.25 FM CW TLM
